o
Dynamic Compression
Compress dynamic range (difference between loud and soft sounds).
Auto:
Automatic dynamic range compression
on/off control according to source.
Low / Medium / High: These set the compression level.
Off:
Dynamic range compression is always
off.
0
“Dynamic Compression” can be set when Dolby Digital, Dolby Digital Plus,
Dolby TrueHD or Dolby Atmos signal is input.
0
The default setting is “Off”. When the input signal is the Dolby TrueHD or
Dolby Atmos source, the default setting is “Auto”.
o
Dialog Control
Adjust the volume of dialog in movies, vocals in music, etc. so these
can be heard more easily.
0 – 6 (Default : 0)
0
This can be set when a DTS:X signal that is compatible with the Dialog
Controll function is input.
o
Low Frequency Effects
Adjust the low frequency effects level (LFE).
-10 dB – 0 dB (Default : 0 dB)
0
For proper playback of the different sources, we recommend setting to the
values below.
0
Dolby Digital sources : 0 dB
0
DTS movie sources : 0 dB
0
DTS music sources: -10 dB
Contents Connections Playback Settings Tips Appendix
157
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X3200W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X3200W and is the answer not in the manual?

Denon AVR-X3200W Specifications

General IconGeneral
Receiver typeSurround
Input sensitivity200 mV
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)180 W
Power output per channel (20-20KHz@8 Ohm)105 W
HDMI in8
Audio (L/R) in5
Composite video in3
USB ports quantity1
Component video (YPbPr/YCbCr) in2
12V triggerYes
Speakers connectivity type-
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Internet radio services supportedvTuner
Optical drive includedNo
DisplayLCD
Product colorBlack
Audio decodersDTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage230 V
AC input frequency50 Hz
Power consumption (typical)650 W
Weight and Dimensions IconWeight and Dimensions
Depth388 mm
Width434 mm
Height167 mm
Weight11300 g
