Denon AVR-X3200W User Manual

Accessories
7
Inserting the batteries
8
Operating range of the remote control unit
8
Features
9
High quality sound
9
High performance
9
Easy operation
12
Part names and functions
13
Front panel
13
Display
16
Rear panel
18
Remote control unit
22
Connections
Connecting speakers
26
Speaker installation
26
Speaker connection
33
Speaker configuration and “Amp Assign” settings
37
Connecting a TV
49
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel)
50
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)
51
Connection 3 : TV equipped without an HDMI connector
52
Connecting a playback device
53
Connecting a set-top box (Satellite tuner/cable TV)
54
Connecting a DVD player or Blu-ray Disc player
55
Connecting a video camcorder or game console
56
Connecting an iPod or USB memory device to the USB port
57
Connecting an FM/AM antenna
59
Connecting to a home network (LAN)
61
Wired LAN
61
Wireless LAN
62
Connecting an external control device
63
REMOTE CONTROL jacks
63
TRIGGER OUT jack
64
Connecting the power cord
65
Playback
Basic operation
67
Turning the power on
67
Selecting the input source
67
Adjusting the volume
68
Turning off the sound temporarily (Muting)
68
Playback a DVD player/Blu-ray Disc player
68
Contents Connections Playback Settings Tips Appendix
Contents
2
Front panel Display Rear panel Remote Index

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
