Playback in ZONE2 (Separate room)
You can operate this unit to enjoy audio in a room (ZONE2) that is different from the room where this unit is placed (MAIN ZONE).
You can simultaneously play back the same source in both the MAIN ZONE and ZONE2. You can also play back separate sources in the MAIN ZONE
and ZONE2.
Connecting ZONE2
You can use the following three methods to play back video and audio in
ZONE2.
0
“Connection through the HDMI ZONE2 connector” (v p. 145)
0
“Connection through the speaker output terminals” (v p. 146)
0
“Connecting using an external amplifier” (v
p. 146)
o
Connection 1 : Connection through the HDMI
ZONE2 connector
When a TV is connected to the HDMI ZONE2 OUT connector, you can
play back a video or audio from the device connected to the HDMI 1 –
7 IN connector in ZONE2 (HDMI ZONE2 function).
.
HDMI
ZONE2
HDMI
MAIN ZONE
ZONE2
When a TV is connected to the HDMI ZONE2 OUT connector, and the MAIN ZONE
and ZONE2 are set to the same input source, the MAIN ZONE audio may be mixed
down to 2-channel audio.
Contents Connections Playback Settings Tips Appendix
145
Front panel Display Rear panel Remote Index

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
