Denon AVR-X3200W User Manual

o
Video Conversion
The input video signal is converted automatically in conjunction with
the connected TV. (v p. 254)
On
(Default):
The input video signal is converted.
Off: The input video signal is not converted.
o
i/p Scaler
Set the video input signal to be subjected to i/p scaler processing.
i/p Scaler will convert the resolution of the input video signal to the
value set in “Resolution”. (v p. 177)
n
When the input source is set other than to “iPod/
USB” and “Online Music”
Analog
(Default):
Use i/p (interlace-to-progressive) scaler
function for analog video signals.
Analog & HDMI:
Use i/p scaler function for analog and
HDMI video signal.
HDMI:
Use i/p scaler function for HDMI video
signals.
Off: Do not use i/p scaler function.
Contents Connections Playback Settings Tips Appendix
176
Front panel Display Rear panel Remote Index

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
