Denon AVR-X4000 Service Manual

3. HDMI/DVI
3.1. No picture or sound is output (HDMI to HDMI)
No picture or sound is output.
Check HDMI/DVI cable connection.
(1) Is the HDMI/DVI cable properly connected?
There may be the a problem with the HDMI/DVI cable. Check
connection.
(2) Are you using an HDMI/DVI selector, repeater or a device for
improving picture quality?
Disconnect everything and connect only the HDMI/DVI cable to
check
(3) Are you using a certied HDMI cable (with the HDMI stamp)?
Use a certied HDMI cable (with the HDMI stamp).
(4) Are you using an HDMI/DVI cable less than 5 meters in
length?
Replace the HDMI/DVI cable with one that is less than 5 meters
in length (2 meters recommended) to check.
(5) Are the picture and sound output when another HDMI/DVI
cable is used?
The HDMI/DVI cable is defective.
Check BD/DVD player.
(6) Is the BD/DVD player's HDMI output setting correct?
Check the HDMI output setting, referring to the BD/DVD
player's operating instructions.
(7) When you use a DENON BD/DVD player's, is the
uorescent display tube's "HDMI" indicator lit? If you use a
non-DENON BD/DVD player's, proceed to "YES".
(8) Are the picture and sound output when the
BD/DVD player's resolution is changed?
Set the BD/DVD player output resolution to a resolution with
which the TV is compatible.
(9) Is sound output from the set's speaker terminals when the
TV's power is turned off or the connection cable between the
TV and the set is disconnected?
The BD/DVD player may not be compatible with HDCP
repeaters. Ask the BD/DVD player's manufacturer.
(10) Are the picture and sound output when a
different BD/DVD player is used?
The BD/DVD player is defective.
YES
NO
YES
YES
NO
YES
YESNO
NO
NO
NO
NO
YES
NO
NO
YES
NO
YES
YES
YES
100

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
