Denon AVR-X4000 Service Manual

Checking the settings
YES
YES
YES
YES
Are the AV RECEIVER's network settings correct?
Are the router, hub and other peripherals properly connected?
Are the router's settings correct?
Set the IP address and other parameters
properly. For a xed IP setting, check
whether the IP address is redundant with
that of other devices, and check whether the
subnet mask setting is correct.
Connect properly to peripherals.
Check the router's operating instructions
and set properly.
Check whether there are connection
restrictions due to the MAC address, etc.
NO
NO
NO
5. Network/USB
5.1. Cannot connect to network
YES
Is the LAN cable properly connected?
Check the LAN cable properly then turn the
power back on.
NO
Checking the environment
The IC322 and surrounding circuitry are defective.
Checking the set (AV RECEIVER)
YES
YES
YES
YES
Is output voltage (3.3V) supplied from IC303?
Is output voltage (1.2V) supplied from IC304?
Is the version of IMG or Ethernet SBL displayed with Version check
mode?
Is a voltage (5V) supplied between CN903 2pin and 4pin?
The IC303 and surrounding circuitry or
circuitry of 3.3v device is defective.
The IC304 or IC390 and surrounding
circuitry is defective.
The rmware of ethernet is defective.
The circuit from AC inlet to CN903 is defective.
NO
NO
NO
NO
105

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
