(4) Disconnect the connector board.
(5) Disconnect the connector board
(6) Cut the wire clamp band, then remove the screws. Disconnect the connector wires and FFC cables.
(7) Disconnect the connector wire.
Board to board
SUPPORT PCB
Board to board
CN932
cut
Shooting direction: C
17
