Denon AVR-X4000 Service Manual

FRONT
FRONT PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D6021 90M-HD302360R DIODE , ZENER ,1/2W, 6.8V ZJ6.8B/HOMI(H.K) COMPANY LTD CVDZJ6.8BT 1
D6023,6024 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 2
D6026 943202007690S DIODE , ZENER ,1/2W, 18V ZJ18B/HOMI(H.K) COMPANY LTD CVDZJ18BT 1
D6027 00D9430087209 DIODE , ZENER ,1/2W, 24V ZJ24B/HOMI(H.K) COMPANY LTD CVDZJ24BT 1
D6041 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D6512 90M-RI000230R RES, CHIP(3216/5%/10ohm) CRJ14CJ100T 1
D6712 00D2760694903 DIODE , ZENER(CHIP,5.1V) ROHM HVDUDZS5.1BSR 1
D6729,6730 00D2760694903 DIODE , ZENER(CHIP,5.1V) ROHM HVDUDZS5.1BSR 2
IC601 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
IC607 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
LD601 943176010090S L.E.D,(GREEN/RED 5PI) BL-BJEGJ204-L/BRIGHT CVDBLBJEGJ204L 1
LD602 963262010460S L.E.D (Infrared light emitting diode) SIR-341ST3F / ROHM ROHM CVDSIR341ST3FT0 1
Q6026 943219006820S T.R CVTKTC1027YT 1
Q6042 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 1
Q6081 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q6112 943215500020S T.R,RT1P141C(10K-10K) RT1P141C(PNP,SC-59,SISAHAYA CVTRT1P141C 1
Q6311,6312 943215500020S T.R,RT1P141C(10K-10K) RT1P141C(PNP,SC-59,SISAHAYA CVTRT1P141C 2
Q6313,6314 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 2
Q6703 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
RESISTOR GROUP
R6001,6002 00MNN05201610 RES, CHIP(1608/5%/200ohm) CRJ10DJ201T 2
R6003,6004 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6005 00MNN05010610 RES, CHIP(1608/5%/1ohm) CRJ10DJ1R0T 1
R6006 nsp RES, CHIP(1608/5%/2.2ohm) CRJ10DJ2R2T 1
R6007 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6016 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R6024 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R6025,6026 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6031 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R6032 00MNN05224610 RES, CHIP(1608/5%/220Kohm) CRJ10DJ224T 1
R6033,6034 90M-RI000230R RES, CHIP(3216/5%/10ohm) CRJ14CJ100T 2
R6041 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6042 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6043 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6044 nsp RES, CHIP(1608/5%/390Kohm) CRJ10DJ394T 1
R6071-6073 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6082 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6083 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6101,6102 nsp RES, CHIP(1608/5%/390ohm) CRJ10DJ391T 2
R6103 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6134 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6135 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6151 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6152 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6153 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6154 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6155 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6161 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6162 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6163 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6164 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6165 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6166 00MNN05561610 RES, CHIP(1608/5%/560ohm) CRJ10DJ561T 1
R6171 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6172 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6173 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6174 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6175 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6301 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6302,6303 00MNN05561610 RES, CHIP(1608/5%/560ohm) CRJ10DJ561T 2
R6351,6352 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6353,6354 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6421,6422 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6423,6424 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6503 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6601,6602 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R6603-6605 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 3
R6607 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6613,6614 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6632 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6704 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6711 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6718 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6719 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R6720 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R6721 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6723 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6726 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6734 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
CAPACIITORS GROUP
C6021 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6022,6023 00MOF15104040 CAP,METAL-FILM(100V/0.1uF) HMFS104J2AP050T CCME2A104JXT 2
C6024 nsp CAP , ELECT(63V/470uF) CCEA1JH471E 1
C6025 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T
1
C6027 nsp
CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C6034 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6071-6073 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 3
C6081 nsp CAP, CHIP(2012, 50V/0.1uF) CCUC1H104KC 1
C6082 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6083 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC 1
C6084 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C6113 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6114 nsp CAP, ELECT(16V/47uF) CCEA1CH470T 1
C6118 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
C6351,6352 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 2
C6417 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC 1
1

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
