Denon AVR-X4000 Service Manual

SPK
SPK PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D9221-9228 90M-HZ200190R DIODE, SWITCHING, SMD TYPE RLS4148 TE-11 HVDRLS4148SR 8
D9230 90M-HZ200190R DIODE, SWITCHING, SMD TYPE RLS4148 TE-11 HVDRLS4148SR 1
D9301 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D9303,9304 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 2
D9315-9318 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 4
D9331 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9333 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9336 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9338-9340 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 3
D9343 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9345 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9348 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9350 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9701 90M-HE200390R DIODE, BRIDGE.(600V/25A) GBJ2506 CVDGBJ2506 1
D9727 00D9430196306 DIODE , ZENER ,1/2W, 7.5V ZJ7.5B/HOMI(H.K) COMPANY LTD CVDZJ7.5BT 1
D9728 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
IC931,932 943231010390S I.C,REGULATOR(+5V,T0220IS) KIA7805BPI (KEC) CVIKIA7805BPI 2
IC933 943232100370S I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1
IC934 943231010390S I.C,REGULATOR(+5V,T0220IS) KIA7805BPI (KEC) CVIKIA7805BPI 1
IC935 00D2631099006 I.C,REGULATOR(-5V,T0220IS) KIA7905PI (KEC) CVIKIA7905PI 1
IC936 00D2631100050 I.C,REGULATOR(+8V,TO-220IS) KIA7808BPI(KEC) CVIKIA7808BPI 1
IC937 00D2631251006 I.C,REGULATOR(-8V,T0220IS) KIA7908PI (KEC) CVIKIA7908PI 1
Q9221-9228 943213500160S T.R,RT1N237C(2.2K-47K) RT1N237C(NPN,SC-59,SISAHAYA CVTRT1N237C 8
Q9230 943213500160S T.R,RT1N237C(2.2K-47K) RT1N237C(NPN,SC-59,SISAHAYA CVTRT1N237C 1
RESISTOR GROUP
R7801,7802 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 2
R9201-9207 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 7
R9211-9217 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 7
R9221-9228 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T 8
R9230 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T 1
R9705,9706 nsp RES, CHIP(3216/5%/470Kohm) CRJ14CJ474T 2
R9711-9713 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 3
R9727 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9801-9804 nsp RES, CHIP(1608/5%/100ohm) E2/E1C/K CRJ10DJ101T 4
R9806 nsp RES, CHIP(1608/5%/100ohm) E2/E1C/K CRJ10DJ101T 1
R9819,9820 00MNN05224610 RES, CHIP(1608/5%/220Kohm) E2/E1C/K CRJ10DJ224T 2
R9821,9822 nsp RES, CHIP(1608/5%/0ohm) E2/E1C/K CRJ10DJ0R0T 2
R9823,9824 00MNN05561610 RES, CHIP(1608/5%/560ohm) E2/E1C/K CRJ10DJ561T 2
CAPACIITORS GROUP
C9211-9217 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 7
C9221 13405014440AS CAP, ELECT(50V/100uF) CCEA1HH101T 1
C9301 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 1
C9303 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C9304 13405012940AS CAP, ELECT(16V/100uF) E2/E1C/K CCEA1CH101T 1
C9305 nsp CAP, ELECT(50V/10uF) E2/E1C/K CCEA1HH100T 1
C9306 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C9309 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1
C9311,9312 943134010600S CAP, ELECT(16V/3300uF) CCEA1CH332E 2
C9315,9316 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 2
C9317 13405014440AS CAP, ELECT(50V/100uF) CCEA1HH101T 1
C9318 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 1
C9321,9322 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 2
C9331-9333 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 3
C9335-9337 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 3
C9511-9521 nsp CAP, CHIP(2012, 250V/0.01uF) CCUC2E103KC 11
C9631-9641 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 11
C9701,9702 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T 2
C9705,9706 963134010180S CAP, ELECT(71V/12000uF),35*58L,NICHICON LKSH2123MESDZT NICHICON CCET71VLKS123N 2
C9708 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
C9727 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C9801-9803 nsp CAP, CHIP(1608, 50V/100pF) E2/E1C/K CCUS1H101JA 3
C9804 nsp CAP, CHIP(1608, 50V/0.1uF) E2/E1C/K CCUS1H104KC 1
C9806 nsp CAP, CHIP(1608, 50V/100pF) E2/E1C/K CCUS1H101JA 1
C9811 nsp CAP, CHIP(1608, 50V/0.1uF) E2/E1C/K CCUS1H104KC 1
OTHER PARTS GROUP
BD981 #N/A FERRITE CHIP BEAD(1608/60R, CB03YTYH600) E2/E1C/K CLZ9R005V 1
BK901,902 nsp BRACKET, PCB(FUSE) CMD1A730 2
BK903 nsp PLATE, MAIN PCB CMC2A424 1
BN701 nsp WIRE ASS'Y LOCKING (9P,2.5MM,180MM,UL1569#20,105) CWB7E0091803D 1
BN702 nsp WIRE ASS'Y LOCKING (7P,2.5MM,400MM,UL1569#20,105) CWB7E0074003D 1
BN703 nsp WIRE ASS'Y LOCKING (3P,2.5MM,220MM,UL1569#24,105) SMH250-03P/CKM2509HV-03P CWB7C0032203D 1
BN782 nsp WIRE ASS'Y LOCKING (5P,2.5MM,100MM,UL1007#20) CWB1E0051003D 1
BN932 nsp WIRE ASS'Y LOCKING (9P,2.0MM,220MM,UL1007#26) CWB1B009220HC 1
CN25B nsp PIN HEADER (21P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP21GI281Z 1
CN77B nsp PIN HEADER (19P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP19GI281Z 1
CN782 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN SMW250-05 CJP05GI289ZY 1
CN932 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/9PIN SMW200-09 CJP09GI288ZY 1
CN940 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN SMW250-05 CJP05GI289ZY 1
CN941 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/3PIN SMW250-03 CJP03GI289ZY 1
CN971 nsp WAFER,YW396-03AB(7.92mm) CJP03GA89ZY 1
F9331-9335 nsp HOLDER , FUSE CJCFC5S 5
GND92 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
JK921-931 943643102420S 2P, SCREW SPK(R/B) SJ2003S-A006-00A200B CJJ5N023Z 11
JW922 nsp WIRE ASS'Y(1P, 150mm, BLUE, UL1007#24) CWE4201150AA 1
JW923 nsp WIRE ASS'Y(1P, 120mm, BLK, UL1015#20, CKM-T) CWE7102120TT 1
L9201-9207 943115010260S COIL , SPEAKER(0.5uH) SPRING COIL 8TS/KSE CLEY0R5KAK 7
RY921-928 682010023006S RELAY,HL3-2A-12S,DC12V,2C1P HL3-2A12S/HANDOUK CSL3A021ZU 8
RY930 943682000810S RELAY,BC3-12H,DC12V,2C2P BC3-12H/HANDOUK CSL4A016ZU 1
TU901 943183100360D TUNER , RDS , FM(PAL TYPE) , SI4705-B20 KST-MW104FV1-S63G E2 CNVMW104FV1-S6
3
1 *
TU901 943183100220S TUNER , NO RDS , FM(PAL TYPE) , SI4704- B20 KST-MW004FV1-S63 E1C CNVMW004FV1-S6
3
1
TU901 943183100220S TUNER , NO RDS , FM(PAL TYPE) , SI4704- B20 KST-MW004FV1-S63 K CNVMW004FV1-S6
3
1
7

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
