DIGITAL
DIGITAL PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D1201 00D2760718902 DIODE, SCHOTTKY, 30V RB521S-30, ROHM ROHM CVDRB521S-30 1
D2301 201310001503S DIODE, ULTRA-HIGH SPEED KDS160-RTK/P, KEC CVDKDS160RTKP 1
D3001,3002 201310001503S DIODE, ULTRA-HIGH SPEED KDS160-RTK/P, KEC CVDKDS160RTKP 2
D3003 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D4003-4006 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 4
IC101 963236101380P I.C, HDMI BUFFER AD8195ACPZ ADI CVIAD8195ACPZ 1
IC121 963236101220D I.C , HDMI RX ADV7850KBCZ-5 ADI CVIADV7850KBCZ-5 1
IC122 963239002150S I.C , OCTAL BUFFER/DRIVER SN74LVC244APWR CVISN74LVC244APW
R
1
IC124 943239100760S I.C , DE/MUX (8CH ANALOG,TSSOP-16P) TOSHIBA CVITC74VHC4051AFT 1
IC151 963236101310S I.C , VSP (WITH HDMI TX,FROM KAGA) ADV8003KBCZ-8C ADI CVIADV8003KBCZ8C
_
1
IC152,153 23981007960AS I.C , DDR2 SDRAM(512M,FBGA-84P) K4T51163QJ-BCE7 SAMSUNG CVIK4T51163QJ-BCE
7
2*
IC155 943248102020D I.C , SERIAL FLASH(128M,SOP-16) MX25L12845EMI10G E3 / E2 /K CVIANAM1808AV 1 *
IC155 943248102030D I.C , SERIAL FLASH(128M,SOP-16) MX25L12845EMI10G E1C CVIANAM1809AV 1 *
IC156 963231101500S I.C, LOW DROP REGULATOR(1.8V,TO-252-5) NJM2846DL3-18 CVINJM2846DL3-18 1
IC201 943243101690D I.C ,CPU(2M/PLQP0144KA-A) R5F56108VNFP RENESAS E3 / E2 /K CVIANAM1802AV 1 *
IC201 943243101700D I.C ,CPU(2M/PLQP0144KA-A) R5F56108VNFP RENESAS E1C CVIANAM1803AV 1 *
IC202 943239100720S I.C , EEPROM(256KBIT,SOP-8P) R1EX24256BSAS0A RENESAS CVIR1EX24256BSAS0
A
1
IC231 943243101710D I.C ,CPU(384K/PLQP0100KB-A) R5F3650KNFB RENESAS CVIANAM1804AV 1 *
IC241 00D2623448908 I.C , 3STATE QUAD BUFFER TC74VHC125FT TOSHIBA CVITC74VHC125FT 1
IC301-307 943239101070S I.C , DC-DC CONVERTER (3A, QFN T&R-24P) CVIEN5339QI 7
IC308 943239100730S I.C , SYSTEM RESET(4.8V , SOT-25A) PST8448NR LELON CVIPST8448NR 1
IC309,310 943239010400S I.C, REGULATOR(3.3V/TO-252) NJM2845DL1-33(TE1) JRC CVINJM2845DL133 2
IC320 943239101090S I.C , High side switch (TSSOP-B8) ROHM CVIBD82065FVJ-E2 1
IC322 943239100700S I.C , Ethernet Transceiver(QFN-24P) LAN8720A-CP-TR CVILAN8720ACPTR 1
IC323 00D2623711004 I.C, VIDEO ENCODER SAA7121H/V2.518 CVISAA7121H/V2.518 1
IC326 23671011050AS I.C , IPOD AUTHENTICATION FROM D&M MFI337S3959 CVI23671011050AS
_
D1
IC390 23681011260AS I.C , Network Media processor(LFBGA-320P) DM860A SMSC CVIDM860A 1
IC392,393 963246100740D I.C , SDRAM(256M,8BIT,TSOP-54P) A3V56S30FTP-G6 ZENTEL CVIA3V56S30FTP-G6 2
IC394 943248102040D 1G NAND FLASH(48P-TSOP1) H27U1G8F2BTR-BC/HYNIHYNIX E3 CVIANAM1810AV 1 *
IC394 943248102050D 1G NAND FLASH(48P-TSOP1) H27U1G8F2BTR-BC/HYNIHYNIX E2 CVIANAM1811AV 1 *
IC394 943248102060D 1G NAND FLASH(48P-TSOP1) H27U1G8F2BTR-BC/HYNIHYNIX K CVIANAM1812AV 1 *
IC394 943248102070D 1G NAND FLASH(48P-TSOP1) H27U1G8F2BTR-BC/HYNIHYNIX E1C CVIANAM1813AV 1 *
IC401 00D2623077900 I.C, HEX INVERTER TOSHIBA HVITC74VHCU04FT 1
IC403 00MHC10418030 I.C , DIR LC89057W-VF4A-E SANYO CVILC89057WVF4AE 1
IC404,405 943236101520D I.C , DIR(SSOP-16) LC89091JA-H CVILC89091JA-H 2
IC406 943249100030D I.C , P-TERM PLD(TQFP-100P) EPM240T100C5N CVIANAM1807AV 1 *
IC407 236810083506S I.C , CLOCK JITTER ICS210010-CZZR CVICS210010-CZZR 1
IC408 943245100360D I.C , DSP(LQFP-176P/350M) ADSP21487KSWZ-3B CVIADSP21487KSWZ
3
1*
IC409 943246012690S I.C , 64M SDRAM W9864G6JH-6 CVIW9864G6JH-6 1
IC410 943248102080D I.C , SERIAL FLASH(16M) MX25L1606EM2I-12G CVIANAM1805AV 1 *
IC421 943245100370D I.C , DSP(LQFP-176P/400M) ADSP21487KSWZ-4B CVIADSP21487KSWZ
4
1*
IC422 943248102090D I.C , SDRAM(256M,16BIT,TSOP-54P) A3V56S40FTP-G6 CVIA3V56S40FTP-G6 1 *
IC423 943248102100D I.C , SERIAL FLASH(16M) MX25L1606EM2I-12G CVIANAM1806AV 1 *
IC441 943239101080S I.C , DAC (8CH , HTSSOP-48) CVIPCM1690DCAR 1 *
IC442,443 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 2
IC445 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
IC447 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
IC451 236810086505S I.C , ADC(96kHz 24-Bit) AK5358BETP/TSSOP-16/AKM CVIAK5358BET 1
IC501 943236101530D I.C , HDMI PORT PROCESSOR SII9575CTUC SILICON IM CVISII9575CTUC 1 *
IC541 943239101080S I.C , DAC (8CH , HTSSOP-48) CVIPCM1690DCAR 1
IC542,543 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 2
IC551 943239010400S I.C, REGULATOR(3.3V/TO-252) NJM2845DL1-33(TE1) JRC CVINJM2845DL133 1
IC552,553 943239100690S I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) PCM5100PWR CVIPCM5100PWR 2
Q1201-1203 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 3
Q1502 90M-HY200050R F.E.T (NEC) CVTUPA672T 1
Q1503 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q1504 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q2301 943215500020S T.R,RT1P141C(10K-10K) RT1P141C(PNP,SC-59,SISAHAYA CVTRT1P141C 1
Q2302,2303 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 2
Q2304,2305 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 2
Q2306 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 1
Q2401 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q2402 963212500030S T.R, ISA1530AC1 ISA1530AC1(PNP,SC-59ISAHAYA CVTISA1530AC1 1
Q2403,2404 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 2
Q2405 963212500030S T.R, ISA1530AC1 ISA1530AC1(PNP,SC-59ISAHAYA CVTISA1530AC1 1
Q2406-2408 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 3
Q2411 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 1
Q2414,2415 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 2
Q2418 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 1
Q3001-3004 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) TPC6111 TOSHIBA CVTTPC6111 4
Q3005 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1 *
Q3006,3007 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 2
Q3008 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q3009 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q3012 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1 *
Q3013 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q3015 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1 *
Q3016 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q3019 00D2710326904 T.R,2SA1954 2SA1954(PNP,SWITCHINTOSHIBA E3 CVT2SA1954 1
Q3020 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA E3 CVTRT1N141C 1
Q3031 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1 *
Q3032 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q3033 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1 *
Q3034 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q3035 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 1
Q3038,3039 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 2
Q4000 213850009503S T.R , 2SC4617EBTLR(NPN,SOT-416, SMALL SIGNAL, ROHM 2SC4617EBTLR ROHM CVT2SC4617EBTLR 1
Q4004 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q4005 963216500060S T.R,RT1N144C(10K-47K) RT1N144C(NPN,SC-59,SISAHAYA CVTRT1N144C 1
Q4006 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q4007 963216500060S T.R,RT1N144C(10K-47K) RT1N144C(NPN,SC-59,SISAHAYA CVTRT1N144C 1
RESISTOR GROUP
R1002 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R1005 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R1007 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R1012,1013 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 2
14
