Ethernet(DM860A) 1st Boot Loader, Hardware ID :
Upper
E t h e r n e t F B L
Lower
* * * * * * - b d
o
Ethernet(DM860A) 2nd Boot Loader :
Upper
E t h e r n e t S B L
Lower
* * * * * * * * * * * * * - 0 A
Q0
Ethernet(DM860A) IMAGE :
Upper
E t h e r n e t I M G
Lower
* * * * * * * * * * * * *
Q1
Ethernet(DM860A)MAC ADDRESS information :
Upper
* E t h e r n e t M A C
Lower
* * * * * * - * * * * * *
Q2
HD RADIO SDK/HD RADIO BBP (AVR-X4000E3 onlly) :
Upper
* H D : * * * * * * * * -
Lower
: * * * * * . * * *
Q3
MultEQ Pro APP :
Upper
* M u l t E Q P r o A P P
Lower
* * . * * . * * . * * * *
Q4
MultEQ Pro ICL :
Upper
* M u l t E Q P r o I C L
Lower
* * . * * . * * . * * * *
1.3. Error display
See the following table for each "Error information" display and its explanation (status).
Display order is
q
,
w
,
e
,
r
,
t
,
y
,
u
,
i
.
Condition Status FL Display Trouble shooting
q
Firm Check
NG
Compared with the destination setting on the
board. This is displayed when the model name
or destination information written into the
rmware does not match. (
b
1)
F I R M E R R O R
• Please check the
destination-resistors
(
R2060/R2061,
DIGITAL B'D).
• Please write the
rmware of correct
destination.
w
SUB NG
No response from SUB microcomputer.
S U B E R R O R 0 1
• Please check SUB
(IC231) and arroud
circuits.
e
IP SCALER
NG
An error has occurred in the i/p Scaler
(ADV8003)initial settings. The error is a DDR
memory Loopback Test error.
I P S C A L E R E R R 0 1
• Please check
ADV8003 (IC151)
and arroud circuits.
Testing writing data between IP SCALER and
DRR resulted in no response.
I P S C A L E R E R R 0 2
r
GUI Version
NG
Error occurs in GUI version and Main μ-com
version.(
b
2)
G U I V E R . E R R O R
• Please check the
rmware of correct
version.
