FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1001 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 1
D1003 90M-HD302360R DIODE , ZENER ,1/2W, 6.8V CVDZJ6.8BT 1
D1004 nsp WIRE, COPPER(D0.6) C3A206 0.02
D1005 00D2760762958 DIODE , ZENER ,1/2W, 39V CVDZJ39BT 1
D1012 943176010090S L.E.D,(GREEN/RED 5PI) CVDBLBJEGJ204L 1
Q1001 943219006820S T.R CVTKTC1027YT 1
Q1003,1004 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1005 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
RC101 943262100140S SENSOR, REMOTE(37.9KHz) CRVHM238RT12 1
RESISTOR GROUP
R1001 nsp RES, CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1004 nsp RES, CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1005,1006 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R1007 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R1008,1009 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R1010 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R1012-1015 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R1016,1017 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R1018,1019 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R1020 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R1021 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1025,1026 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 2
R1030 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1041,1042 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R1043 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1046 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1053 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R1057 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R1058,1059 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R1060,1061 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R1067 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1068 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R1069 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1071 nsp RES, CHIP(1608/5%/5.6Kohm) E3 CRJ10DJ562T 1
R1072 nsp RES, CHIP(1608/5%/3.3Kohm) E3 CRJ10DJ332T 1
R1073 nsp RES, CHIP(1608/5%/2.7Kohm) E3 CRJ10DJ272T 1
R1073,1074 nsp RES, CHIP(1608/5%/1.5Kohm) E2, E1C CRJ10DJ152T 2
R1074,1075 nsp RES, CHIP(1608/5%/1Kohm) E2, E1C CRJ10DJ102T 2
R1075 nsp RES, CHIP(1608/5%/0ohm) E2, E1C CRJ10DJ0R0T 1
R1076 nsp RES, CHIP(1608/5%/5.6Kohm) E3 CRJ10DJ562T 1
R1077 nsp RES, CHIP(1608/5%/3.3Kohm) E3 CRJ10DJ332T 1
R1077 nsp RES, CHIP(1608/5%/1.5Kohm) E2, E1C CRJ10DJ152T 1
R1078 nsp RES, CHIP(1608/5%/2.7Kohm) E3 CRJ10DJ272T 1
R1078 nsp RES, CHIP(1608/5%/1Kohm) E2, E1C CRJ10DJ102T 1
R1079 nsp RES, CHIP(1608/5%/1.5Kohm) E3 CRJ10DJ152T 1
R1079 nsp RES, CHIP(1608/5%/0ohm) E2, E1C CRJ10DJ0R0T 1
R1080 nsp RES, CHIP(1608/5%/1Kohm) E3 CRJ10DJ102T 1
R1080 nsp RES, CHIP(1608/5%/0ohm) E2, E1C CRJ10DJ0R0T 1
R1081 nsp RES, CHIP(1608/5%/5.6Kohm) E3 CRJ10DJ562T 1
R1082 nsp RES, CHIP(1608/5%/3.3Kohm) E3 CRJ10DJ332T 1
R1082,1083 nsp RES, CHIP(1608/5%/2.7Kohm) E2, E1C CRJ10DJ272T 2
R1083,1084 nsp RES, CHIP(1608/5%/1.5Kohm) E2, E1C CRJ10DJ152T 2
R1084,1085 nsp RES, CHIP(1608/5%/1Kohm) E2, E1C CRJ10DJ102T 2
R1085 nsp RES, CHIP(1608/5%/0ohm) E2, E1C CRJ10DJ0R0T 1
R1413,1414 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R1415,1416 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R1423 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
CAPACIITORS GROUP
C1002 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C1003 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C1004 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C1005 nsp CAP , ELECT(63V/100uF) CCEA1JH101E 1
C1006 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C1007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1009 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CCUC1H104KCS 1
C1010 nsp CAP, ELECT(16V/10uF)-S CCEA1CKS100T 1
C1011 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1013,1014 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG 1608, 50V/100pF, C0G CCUS1H101JAS 2
C1015 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG 1608, 50V/330pF, C0G CCUS1H331JAS 1
C1016 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG 1608, 50V/1000pF, X7R CCUS1H102KCS 1
C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1019 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C1020 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C1038 nsp CAP, ELECT(16V/47uF)-S CCEA1CKS470T 1
C1039 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG 1608, 50V/100pF, C0G CCUS1H101JAS 1
C1054,1055 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C1065 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C1066 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1067 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C1068 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1071,1072 nsp CAP, CHIP(1608, 50V/680pF, C0G)_SAMSUNG 1608, 50V/680pF, C0G CCUS1H681JAS 2
C1073 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1076,1077 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C1081 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1424 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1425,1426 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
OTHER PARTS GROUP
CN102 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1
CN103 nsp LOCK-WAFER/ANGLE/2MM PITCH/3PIN CJP03GJ288ZY 1
CN104 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/3PIN CJP03GI288ZY 1
BK101,102 nsp BRACKET , FIP CMD1A572-V1 2
BN101 nsp WIRE ASS'Y B'D-B'D IN (9P,2MM,80MM,#28) CWB1A009080CC 1
BN12B1 nsp WAFER,FFC 1.25mm,ANGLE CJP27GB286ZN 1
BN131 nsp WIRE ASS'Y Locking (YH) (3P,2MM,50MM,#28) CWB1A003050HC 1
! F1001 943652500600S FUSE(932Series, 250V/200mA) E3 CBA2J0200TLUBT 1 *
! F1001 943652500550D FUSE(372 Series/200mA/TR5) 372 Series/200mA E2, E1C CBA2D0200A3EYT 1
FL101 943172100150S V.F.D (FUTABA, 18-BT-021GINK) CFL18BT021GINK 1
J1001-1012 nsp WIRE, COPPER(D0.6) C3A206 12
J1014-1054 nsp WIRE, COPPER(D0.6) C3A206 41
J1056-1059 nsp WIRE, COPPER(D0.6) E3 C3A206 4
1

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
