Denon AVR-X520BT Service Manual

22
3. ChangeVideoFormatandDisplayLanguageMode
3.1. Operations
Hold down buttons below for at least 3 seconds while the power is on.
"PRESET -", "PRESET +", "TUNE -" (AVR-S510BT)
"TUNE -", "TUNE +", "DIMMER" (AVR-X520BT / X518CI)
f
Note: Do not start in this mode when displaying the OSD MENU using the MENU button.
3.2. Actions
This unit is in VIDEO Format at startup.
Press the button below to switch between Video Format and Display Language.
"TUNE +" AVR-S510BT
"STATUS" AVR-X520BT / X518CI
f
3.2.1.VideoFormat
Press the button below to switch between NTSC and PAL.
"PRESET +" or "TUNE -" AVR-S510BT
"PRESET +" or "DIMMER" AVR-X520BT / X518CI
f
FLD
V . F o r m a t : < N T S C >
↓↑
FLD
V . F o r m a t : < P A L >
↓↑
Return to top.
Press the "Preset -" button to set format. The display then return to the normal mode.
3.2.1.Language
Press the button below to switch display language.
"PRESET +" or "TUNE -" AVR-S510BT
"PRESET +" or "DIMMER" AVR-X520BT / X518CI
f
FLD
L a n g . : < E N G L I S H >
↓↑
FLD
L a n g . : < S P A N I S H >
↓↑
FLD
L a n g . : < F R E N C H >
↓↑
FLD
L a n g . : < C H I N E S E >
↓↑
Return to top.
Press the "Preset -" button to set display language. The display then return to the normal mode.

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
