Denon AVR-X520BT Service Manual

46
NO
NO
NO
Is IC601 (TOP268VG) damaged?
Is there the damage in D6001 - D6004?
Repair the short circuited area(s) by the
soldering of the PCB.
Check the damage of each part.
Replace the damaged part(s).
Replace the damaged part(s).
Has a fuse (F6001) broken?
Are there any short circuits caused by
the soldering of the PCB?
Are any parts damaged?
Replace the IC601 (TOP268VG) and
D6001 - D6004.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
