Denon AVR-X520BT Service Manual

45
Check the USB device being used
YES
Is the USB device supported by this unit?
Is a USB hub being used?
This unit supports devices in the FAT16 and
FAT32-formatted mass storage class, MTP-
compatible devices and iPods (with the
exception of some models).
Do not use a USB hub.
NO
YES
NO
Checking the unit
YES
YES
Can a voltage (5V) be conrmed between pin 1 and pin 4 of JK91 (USB
Connector) on USB PCB?
The circuit between IC901 and JK91 of the USB PCB are faulty.
Are BN912 and BN914 of the USB PCB correctly connected?
IC905 around circuit of the DIGITAL PCB is
faulty.
Connect the connectors correctly.
NO
NO
5.2. A connected USB device is not recognized.

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
