Denon AVR-X520BT Service Manual

USB
USB PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1401 943202500730S DIODE , ZENER(5.1V/0.5W, SOD-123) CVDMM1Z5V1H 1
D1404,1405 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 2
D9010,9011 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 2
D9012-9015 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI
1
4
IC101 00D2631289900 OPAMP(DUAL/LOW NOISE) CVIAZ4580MTR-E1 1
IC901 943243102260D I.C , SYSTEM CONTROLLER(TQFP-128P) CVIBX8804 1
IC902 943246101120S I.C , 64M SDRAM CVIW9864G6KH-6 1 *
IC903 23671011050AS I.C , IPOD AUTHENTICATION FROM D&M CVI23671011050AS
_
1
IC904 943189101590S I.C , USB_BLUETOOTH (AVR-S510BT_X520BT) CVIANAM2099AV 1 *
┗IC904 - I.C , SERIAL FLASH
(
16M
)
CVIMX25L1606EM2I 1
IC905 943239101090S I.C , High side switch (TSSOP-B8) CVIBD82065FVJ-E2 1
IC906 943239100690S I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC909 943231101880D IC, regulator(1.2V , SSOP5) CVIBU12TD3WG 1
IC910 943231102170S IC, regulator(3.3V , SSOP5) CVIBU33TD3WG 1 * 2
RESISTOR GROUP
R1027 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1401 nsp RES, CHIP(1005/5%/56Kohm) CRJ06IJ563T 1
R1402 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R1403,1404 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R1405 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1406 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1407 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R1408 nsp RES, CHIP(1608/5%/56Kohm) CRJ10DJ563T 1
R1409 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1411 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R9010 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9012 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R9017 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9018-9020 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 3
R9022-9024 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R9026 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9028-9031 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 4
R9032 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R9033 nsp RES, CHIP(1005/5%/1Mohm) CRJ06IJ105T 1
R9034-9038 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 5
R9041-9043 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 3
R9044 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9045-9049 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 5
R9050-9061 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 12
R9066 nsp RES, CHIP(1005/5%/560ohm) CRJ06IJ561T 1
R9067-9069 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R9070-9072 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 3
R9073,9074 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 2
R9075,9076 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R9077 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9078 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9079-9085 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 7
R9086 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9088 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9089 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9090,9091 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R9092 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9093 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
RN901-908 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 8
RN909 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
CAPACIITORS GROUP
C1401 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1402 nsp CAP, SMD ELECT(50V/1uF) CCEC1HMVG1R0T 1
C1403 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG 1608, 50V/100pF, C0G CCUS1H101JAS 1
C1405 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C1406 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1407 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) CCEC1CMVG101T 1
C1408 nsp CAP, CHIP(1608, 50V/27pF, C0G)_SAMSUNG CCUS1H270JAS 1
C1410,1411 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 2
C1413,1414 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C1415 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG 1608, 50V/1000pF, X7R CCUS1H102KCS 1
C1416 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1417 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9010,9011 nsp CAP,ALUMINUM ELECTROLYTIC (6.3V/220uF) CCEC0JMVG221T 2
C9012 nsp CAP,ALUMINUM ELECTROLYTIC (6.3V/47uF) CCEC0JMVG470T 1
C9014 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C9015-9023 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 9
C9026,9027 nsp CAP, CHIP(1608, 50V/2200pF, X7R)_SAMSUNG CCUS1H222KCS 2
C9028 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9029,9030 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C9033,9034 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 2
C9035,9036 nsp CAP, CHIP(1608, 6.3V/2.2uF, X7R)_SAMSUNG CCUS0J225KCS 2
C9039-9056 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 18
C9058-9063 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 6
C9064-9068 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 5
C9069 nsp CAP, CHIP(1005, 50V/10pF, C0G)_SAMSUNG CCUI1H100JAS 1
C9072-9085 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS 14
C9086,9087 nsp CAP, CHIP(1005, 50V/15pF, C0G)_SAMSUNG CCUI1H150JAS 2
C9088,9089 nsp CAP, CHIP(1005, 50V/220pF, C0G)_SAMSUNG CCUI1H221JAS 2
C9090-9093 nsp CAP, CHIP(1005, 50V/33pF, C0G)_SAMSUNG CCUI1H330JAS 4
C9094 nsp CAP, CHIP(1005, 50V/47pF, C0G)_SAMSUNG CCUI1H470JAS 1 *
C9095-9100 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 6
C9103 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9109 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9110 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9111 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C9112 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C9113 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) CCEC1CMVG100T 1
C9114-9130 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 17
OTHER PARTS GROUP
CN911 nsp WAFER , CARD CABLE (SMD, 09P-1mm, ANGLE, H : 2mm) CJP10GB310ZY 1
BN912 nsp WIRE ASS'Y Locking (YH) (15P,2MM,280MM,#26) CWB1B015280HC 1
BN914 nsp WIRE ASS'Y Locking (YH) (7P,2MM,280MM,#26) CWB1C007280HC0
0
1
JK105 943643102930S JACK, STEREO, 3.5mm MINI, BLACK MOLD CJJ2D029Z 1
JK91 943643101590S JACK, USB STRAIGHT(BLACK 1.5A) CJJ9X010Z 1
L1401 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L9010,9011 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 2
L9013-9015 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 3
L9018,9019 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 2
L9023,9024 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
3

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
