Denon AVR-X520BT Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
R7614 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R7615,7616 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R7617,7618 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 2
R7619,7620 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R7621,7622 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 2
R7623,7624 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7625 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7626 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7627 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7633,7634 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7637 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7638 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7639,7640 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 2
R7647 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R7648 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R7649 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7650 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7651 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7652 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R7653 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7655 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7656,7657 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 2
R7664-7668 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 5
R7670-7673 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 4
R7674,7675 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 2
R7676,7677 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
R7678 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7679 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7680 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7681 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7682,7683 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7686-7689 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 4
R7690 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7691 nsp RES, CHIP(1608/0.5%/8.2Kohm) CRJ06DD822TP 1
R7692,7693 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
R7694 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7695 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7696 nsp RES, CHIP(1608/0.5%/8.2Kohm) CRJ06DD822TP 1
R7697 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7698,7699 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7702-7705 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 4
R7706,7707 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 2
R7708,7709 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
R7710 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7711 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7712 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7713 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7714,7715 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7718,7719 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R7723-7726 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R7727 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7729 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R7730 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7732 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7736,7737 nsp RES, M-OXIDE FILM(1W/150ohm) 1W/150ohm CRG1SANJ151RT 2
R7738 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7741 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7742 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R7744 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7745 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7747 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7748 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7752 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7753 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7754,7755 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R7756 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7757 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R7758 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7762,7763 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R7774-7779 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
R7781 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7811 nsp RES, CHIP(1005/5%/75ohm) CRJ06IJ750T 1
RN711,712 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 2
RN731-733 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
RN734 943113100000S COMMON MODE FILTER (1210, 90ohm) CLZ9Z188Z 1
RN741,742 nsp RES, CHIP(1005/5%/10Kohm*4) CRJ064IJ103T 2
RN743-751 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 9
CAPACIITORS GROUP
C7101,7102 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 2
C7103,7104 nsp CAP, CHIP(1608, 50V/20pF, C0G)_SAMSUNG CCUS1H200JAS 2
C7105,7106 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 2
C7110-7121 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 12
C7124-7128 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 5
C7129-7131 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 3
C7132 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7133 nsp CAP, ELECT(10V/100uF) CCEA1AH101T 1
C7141-7145 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 5
C7201-7208 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 8
C7209 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7210 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7211 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7212 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7213 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7216,7217 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 2
C7218 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C7221-7224 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 4
C7225 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7226 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7227 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7231 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7234-7239 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 6
C7240,7241 nsp CAP, CHIP(1608, 50V/15pF, C0G)_SAMSUNG CCUS1H150JAS 2
C7242 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7244 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7245 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7246 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7270-7279 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 10
C7280 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7281 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7285 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7301,7302 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 2
C7303-7305 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C7306 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
11

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
