Denon AVR-X520BT Service Manual

AVR-X518CI_EXPLODED
AVR-X518CI_EXPLODED
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
P1 ns
p
FRONT PCB ASS'Y COP12736I 1
┣P2 ns
p
STANDBY PCB ASS'Y COP12736I 1
┗P3 ns
p
PHONE PCB ASS'Y COP12736I 1
P4 9U6391021300
S
USB&MIC PCB ASS'Y COP12743B 1
P5 943639101390
D
MODULE, BLUETOOTH CNVMB8811C0B 1
P6 ns
p
MAIN PCB ASS'Y COP12741D 1
┣P7 ns
p
PHONE WIRE GUIDE COP12741D 1
┣P9 ns
p
TUNER PCB ASS'Y COP12741D 1
┣P10 ns
p
VIDEO PCB ASS'Y COP12741D 1
┣P13 ns
p
FRONT CABLE GUIDE COP12741D 1
┗P14 ns
p
USB WIRE GUIDE COP12741D 1
P8 943639102050
S
HDMI PCB ASSY
(
E1C
)
COP12742F 1
P11 ns
p
REGULATOR PCB ASS'Y VOP12742G 1 *
┗P12 ns
p
POWER
(
SMPS
)
PCB ASS'Y VOP12742G 1 *
! P15 943101102400D TRANS,POWERAVR-X510BT/E1C,(85.8X57) VLT5U056ZH 1
F1 943412100710D KNOB,VOLUME CBN1A263 1
F2 943446100590D PLATE,VOLUMEKNOB CGX1A469 1
F3 943412101070D KNOB,SELECT CBN1A274 1
F4 943446100760D PLATE,SELECTKNOB CGX1A481 1
F6 943416101320D WINDOW VGU1A462N 1
F7 42141002400AD BADGE,DENON CGB1A254Z-V1 1
F8 943402106380S FRONT/SUBPANELASS'Y VGW1A553FA 1 *
F9 943411101750D BUTTON,POWER CBT1A1167 1
F10 943423100510D INDICATOR,POWER CGL1A299A36 1
F11 943411101770D BUTTON,10KEY VBT2A1164 1
F12 nsp HOLDER,BT VMH1A356 1
F13 nsp PLATE,EARTHUSB VMC1A430 1
M1 nsp CHASSIS,BOTTOM VUA4A335 1
M2 nsp RUBBER VHG1A113 1
M3 nsp LABEL,BOTTOM VQB1A1243 1
M4 943407100020D FOOT CKL1A190 4
M5 00D9630214607 CUSHIONFOOT VHG2A289 4
M6 nsp HEATSINK,MAIN VMY1A409 1
M7 nsp HOLDER,PCB CHE170 2
M8 nsp BRACKET,SMPS VMD1A790 1
M9 nsp BRACKET,PCN VMD1A774 2
M10 nsp PANEL,REAR VKF3A481AU 1
M11 nsp BUSHING,ACCORD CHR1A028 1
M12 943403100570D CABINET,TOP VKC1A215K117 1
S1 ns
p
SCREW VTB3+6JR 5
S2 ns
p
SCREW VTW3+6JR 2
S3 ns
p
SCREW VTB3+6FFZR 13
S4 ns
p
SCREW VTB3+8JR 30
S5 ns
p
SCREW VTB3+8JFZR 5
S6 ns
p
SCREW VTBD3+8JFZR 18
S7 ns
p
SCREW VTW3+8JR 9
S8 ns
p
SCREW VTW3+12JR 2
S9 ns
p
SCREW CTBD4+8JFZR 6
S10 ns
p
SCREW VHDR1A023
R
4
S11 ns
p
SCREW VHD4A012
R
3
S12 ns
p
SCREW VHD1A012Z
R
15
S13 ns
p
SCREW VTWS3+10GR 1
S14 ns
p
SCREW CTB3+6FR 4
★ ns
p
LABEL,POP CQB1A1540Z 1 *
16

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
