1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
t
,
y
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
NG
The model name, brand name and region information written in the rmware are compared
to the region settings in the PCB. This error is displayed if the information does not match.
" ▲ " is displayed as the rst character if the rmware is not correct (see the illustrations on
the right).
FIRM ERROR
–
M:*************
–
Main FBL :**.**
–
DSP# :**.**
–
Audio PLD:**.**
–
Video PLD:**.**
–
GUI :********
• Check the resistor for setting the region[R6217, R6218,
R6219, DIGITAL PCB].
• Write the rmware for the correct region.
w
IP SCALER NG
An error occurs in Loop back Test of the DDR memory which is performed during the initial
setting of i/p Scaler(ADV8003).
IP SCALER ERR 01
• Check the circuits around the IP SCALER [U2800, DIGITAL
PCB] and DDR2 [U3000/U3001].
If there appear to be no problems, [U2800] or [U3000/U3001]
is faulty.
During the initial setting of i/p Scaler ( ADV8003 ) , there is not the reply of the Loop back Test
result of the DDR memory .
IP SCALER ERR 02
e
GUI Serial
Flash NG
If the Main CPU version is not supported by the GUI Serial Flash (ADV8003),
" ▼ " is displayed as the rst character of the GUI rmware version.
If GUI Serial Flash is damaged, " ▲ " is displayed as the rst character.
GUI VER. ERROR
•
GUI :********
–
GUI :********
• Check the rmware version.
r
DIR NG
This error is displayed if there is no response from the DIR.
DIR ERROR 01
• Check the DIR [U7004, DIGITAL PCB] and surrounding cir-
cuits.
t
DSP
#
NG
(
#
: 1/2/3/4)
Boot error 1 (After reset the DSP, DSP_Flag0 port is "Low")
DSP# ERROR 01
• Check the DSP [U101, U201, U301, U401, DIGITAL PCB] and
surrounding circuits.
Boot error 2 (After reset the DSP, DSP initialization is not completed)
DSP# ERROR 02
(Unused)
DSP# ERROR 03
Command error 1 (After sending the command to the DSP, DSP_Flag0 port is "Low".)
DSP# ERROR 04
Command error 2 (After sending the command to the DSP, MCU received "COMMAND ER-
ROR".)
DSP# ERROR 05
Command error 3 (After sending the command to the DSP, MCU did not receive "COMMAND
SUCCESS".)
DSP# ERROR 06
IDL error 1 (Before receiving IDL, "COMMAND BYTE" is not cleared.)
DSP# ERROR 07
IDL error 2 (MCU received "IDL SERIOUS ERROR".)
DSP# ERROR 08
SPI communication error
DSP# ERROR 09
y
BACKUP NG
Error occurred in BACKUP. it is an error of the check sum.
BACKUP ERROR
