Denon AVR-X6500H

Paths to be conrmed Display Settings What to conrm
8
Analog Amp Assign
(Amp Assign :
ZONE3)
g.A08
A08:ASSIGN-Z3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z3 Source : Source
Amp assign : 9.1ch + ZONE3
Speaker for ZONE3 : Height2
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : On
・ Analog input ⇒ Speaker output (Height 2 (ZONE3) L/R)
・ Analog input ⇒ Pre OUT output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
9
Analog Amp Assign
(Amp Assign :
ZONE2/ZONE3-
MONO)
g.A09
A09:ASSIGN-Z2/3M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Z3 Source : Source
Amp assign : 9.1ch + ZONE2/3
Speaker for ZONE2/3 : Height2
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : On
・ Analog input ⇒ Speaker output (Height2 (ZONE2 MONO L), Height2 (ZONE3 MONO) R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R MONO, ZONE3 L/R MONO)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
10
Amp Assign
(Amp Assign :
BiAMP)
g.A10a
g.A10b
A11:ASSIGN-BiAMP
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch + BiAMP
Speaker for Bi-Amp : S.Back
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (S.Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
11 Front Height
g.A11a
g.A11b
A14:FRONT HEIGHT
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 11.1ch
Floor Layout : 5ch&SB
Height Sp : 4ch
Dolby Sp : None
Height Layout : Top Front & Top Rear
Speaker Select=Floor & Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (Height1 L/R (Top Front), Height2 L/R (Top Rear))
・ Analog input ⇒ Pre OUT output (Height1 L/R (Top Front), Height2 L/R (Top Rear))
・ Pre OUT 出力
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
1.6. Conrmation items for the video system
See the block diagram g.VXXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.V01
V01:VIDEO PASS
Input Source : DVD
Video Convert (IP Scaler) : "OFF" All sources
MAIN ZONE : On
ZONE2 : On
・ Component input ⇒ Component output
(
b
The input source can be switched to any source except CBL/SAT.)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
157
