Denon AVR-X6500H

RCSHP0420015
１１１１００
RCSHP0420031
１１１１１０
No.
Data (C6～C11)
Key Name No.
Data (C6～C11)
Key Name
RCSHP0420032
０００００１
RCSHP0420048
００００１１
RCSHP0420033
１００００１
RCSHP0420049
１０００１１
RCSHP0420034
０１０００１
RCSHP0420050
０１００１１
RCSHP0420035
１１０００１
RCSHP0420051
１１００１１
INPUT MDOE AUTO
RCSHP0420036
００１００１
RCSHP0420052
００１０１１
RCSHP0420037
１０１００１
RCSHP0420053
１０１０１１
RCSHP0420038
０１１００１
RCSHP0420054
０１１０１１
RCSHP0420039
１１１００１
RCSHP0420055
１１１０１１
RCSHP0420040
０００１０１
RCSHP0420056
０００１１１
RCSHP0420041
１００１０１
RCSHP0420057
１００１１１
RCSHP0420042
０１０１０１
RCSHP0420058
０１０１１１
RCSHP0420043
１１０１０１
RCSHP0420059
１１０１１１
RCSHP0420044
００１１０１
RCSHP0420060
００１１１１
RCSHP0420045
１０１１０１
RCSHP0420061
１０１１１１
RCSHP0420046
０１１１０１
RCSHP0420062
０１１１１１
RCSHP0420047
１１１１０１
RCSHP0420063
１１１１１１
FORMAT KASEIKYO
DATA CONSTRUCTION 48bits
DENON CODE Parity GENRE1(*1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 * * * *
GENRE2(*2) Data ID(*3) Parity(*5)
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
* * * * * * * * * * * * * * * * * * * * * * * *
(*5) Parity :
Delimit of each to 8 bits, and add the 3rd byte and the 4th byte and the 5th byte with modulo 2(exclusive-OR).
3rd byte ( 17 - 24 bit)
4th byte ( 25 - 32 bit)
5th byte ( 33 - 40 bit)
REMOTE ID SETTING: (default ID 1)
ID No. ZONE/DEVICE
GENRE1(*1)
GENRE2(*2) ID(*3)
21 22 23 24 25 26 27 28 39 40
1
MAIN ZONE 0
0 1 0 1 0 0 0 0 0 SHARP&K4-1
ZONE2 0 0 1 0 1 1 0 0 0 0 SHARP&K4-3
ZONE3 0 0 1 0 1 0 1 0 0 0 SHARP&K4-5
TUNER 0 0 1 0 1 0 0 0 0 0 SHARP&K4-1
HEOS MUSIC 0 0 1 0 1 1 1 0 0 0 K4-7
2
MAIN ZONE 0
0 1 0 0 1 0 0 1 0 K4-2
ZONE2 0 0 1 0 0 0 1 0 1 0 K4-4
ZONE3 0 0 1 0 0 1 1 0 1 0 K4-6
TUNER 0 0 1 0 0 1 0 0 1 0 K4-2
HEOS MUSIC 0 0 1 0 0 0 0 1 1 0 K4-8
3
MAIN ZONE 0
0 1 0 0 1 0 0 0 1 K4-2
ZONE2 0 0 1 0 0 0 1 0 0 1 K4-4
ZONE3 0 0 1 0 0 1 1 0 0 1 K4-6
TUNER 0 0 1 0 0 1 0 0 0 1 K4-2
HEOS MUSIC 0 0 1 0 0 0 0 1 0 1 K4-8
4
MAIN ZONE 0
0 1 0 0 1 0 0 1 1 K4-2
ZONE2 0 0 1 0 0 0 1 0 1 1 K4-4
ZONE3 0 0 1 0 0 1 1 0 0 1 K4-6
TUNER 0 0 1 0 0 1 0 0 1 1 K4-2
HEOS MUSIC 0 0 1 0 0 0 0 1 1 1 K4-8
MAIN ZONE
REMOTE ID SET: 1
DENON CODE
Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4
1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 1 0 0 0
REMOTE ID SET: 2-4
DENON CODE
Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4
2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 0 1 0 0
No. Data ID parity Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0410001 1 0 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER ON/OFF
RCKSK0410002 0 1 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER ON
RCKSK0410003 1 1 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER OFF
RCKSK0410006 0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE ON
RCKSK0410007 1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE OFF
RCKSK0410012 0 0 1 1 0 0 0 0 0 0 * * * * * * * * * * TRIGGER-1 ON
RCKSK0410013 1 0 1 1 0 0 0 0 0 0 * * * * * * * * * * TRIGGER-1 OFF
RCKSK0410014 0 1 1 1 0 0 0 0 0 0 * * * * * * * * * * TRIGGER-2 ON
RCKSK0410015 1 1 1 1 0 0 0 0 0 0 * * * * * * * * * * TRIGGER-2 OFF
RCKSK0410016 0 0 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY1
RCKSK0410017 1 0 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY2
RCKSK0410018 0 1 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY3
RCKSK0410019 1 1 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY4
RCKSK0410020 0 0 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY5
RCKSK0410021 1 0 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY6
RCKSK0410022 0 1 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY7
RCKSK0410023 1 1 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY8
RCKSK0410024 0 0 0 1 1 0 0 0 0 0 * * * * * * * * * * KEY9
RCKSK0410025 1 0 0 1 1 0 0 0 0 0 * * * * * * * * * * KEY0
RCKSK0410027 1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR UP
RCKSK0410028 0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR DOWN
RCKSK0410029 1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR LEFT
RCKSK0410030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR RIGHT
RCKSK0410031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ENTER
RCKSK0410034
0 1 0 0 0 1 0 0 0 0 * * * * * * * * * *
RETURN/BACK
RCKSK0410035
1 1 0 0 0 1 0 0 0 0 * * * * * * * * * *
SETUP MENU
RCKSK0410036
0 0 1 0 0 1 0 0 0 0 * * * * * * * * * *
MEMORY
RCKSK0410042
0 1 0 1 0 1 0 0 0 0 * * * * * * * * * *
UPGRADE ID ON
RCKSK0410045 1 0 1 1 0 1 0 0 0 0 * * * * * * * * * * Bilingual Mode(toggle) (JP only)
RCKSK0410112 0 0 0 0 1 1 1 0 0 0 * * * * * * * * * * VIDEO SELECT
RCKSK0410292
0 0 1 0 0 1 0 0 1 0 * * * * * * * * * *
QUICK SELECT 1
RCKSK0410293 1 0 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 2
RCKSK0410294 0 1 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 3
RCKSK0410295 1 1 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 4
RCKSK0410296 0 0 0 1 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 5
RCKSK0410304 0 0 0 0 1 1 0 0 1 0 * * * * * * * * * * STEREO
RCKSK0410305 1 0 0 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT/STEREO
RCKSK0410306 0 1 0 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT
RCKSK0410307 1 1 0 0 1 1 0 0 1 0 * * * * * * * * * * PURE DIRECT
RCKSK0410308 0 0 1 0 1 1 0 0 1 0 * * * * * * * * * * STANDARD
RCKSK0410309 1 0 1 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT
RCKSK0410320 0 0 0 0 0 0 1 0 1 0 * * * * * * * * * * DTS SURROUND
RCKSK0410324 0 0 1 0 0 0 1 0 1 0 * * * * * * * * * * AUTO SOUND
RCKSK0410329 1 0 0 1 0 0 1 0 1 0 * * * * * * * * * * MOVIE SURROUND
RCKSK0410330 0 1 0 1 0 0 1 0 1 0 * * * * * * * * * * MUSIC SURROUND
RCKSK0410331 1 1 0 1 0 0 1 0 1 0 * * * * * * * * * * GAME SURROUND
RCKSK0410332 0 0 1 1 0 0 1 0 1 0 * * * * * * * * * * SURROUND MODE toggle(Reverse)
RCKSK0410336 0 0 0 0 1 0 1 0 1 0 * * * * * * * * * * DSP SIMULATION
RCKSK0410337 1 0 0 0 1 0 1 0 1 0 * * * * * * * * * * MULTI CH STEREO
RCKSK0410340 0 0 1 0 1 0 1 0 1 0 * * * * * * * * * * ROCK ARENA
RCKSK0410341 1 0 1 0 1 0 1 0 1 0 * * * * * * * * * * JAZZ CLUB
RCKSK0410343 1 1 1 0 1 0 1 0 1 0 * * * * * * * * * * MONO MOVIE
RCKSK0410344 0 0 0 1 1 0 1 0 1 0 * * * * * * * * * * MATRIX
RCKSK0410345 1 0 0 1 1 0 1 0 1 0 * * * * * * * * * * VIDEO GAME
RCKSK0410346 0 1 0 1 1 0 1 0 1 0 * * * * * * * * * * VIRTUAL
RCKSK0410348 0 0 1 1 1 0 1 0 1 0 * * * * * * * * * * Dolby Atmos ON/OFF
RCKSK0410349 1 0 1 1 1 0 1 0 1 0 * * * * * * * * * * SURROUND MODE toggle(Normal)
RCKSK0410352 0 0 0 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE SELECT
RCKSK0410353 1 0 0 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE:ANALOG
RCKSK0410357 1 0 1 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE HDMI
RCKSK0410358 0 1 1 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE:AUTO
RCKSK0410359 1 1 1 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE DIGITAL
