Denon AVR-X8500H Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Switch the PANEL LOCK and REMOTE LOCK modes between on and off.
2.2. Starting up
While holding down buttons "
STATUS
" and "
INFO
" simultaneously, press the power button to turn on
the power.
Select the desired mode using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to conrm.
2.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
CURSOR
f
/
d
" button is pressed.
Press the "
ENTER
" button to set the currently displayed mode and restart the device.
The setting with "
*
" is selected for each mode.
q
L1
–FP/VOL LOCK*On
L2
FP LOCK On
The buttons on the unit and the master volume knob does not function.
w
L1
FP/VOL LOCK*On
L2
–FP LOCK On
The buttons on the unit does not function.
e
L1
FP LOCK On
L2
–FP LOCK Off
The PANEL LOCK mode is turned off.
r
L1
FP LOCK Off
L2
–RC LOCK On
The device cannot be operated by the remote control.
t
L1
RC LOCK On
L2
–RC LOCK *Off
The REMOTE LOCK mode is turned off.
