Denon AVR-X8500H Service Manual

3-1. Selecting the Mode for Service-related
3-1.1. Actions
Select diagnostic mode (service path check mode), protection history display mode, 232C standby clear
mode, Operation Info mode, TUNER STEP mode or Remote ID Setup Mode.
3-1.2. Starting up
While holding down buttons "
ZONE3 SOURCE
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
Select the desired mode using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to conrm.
3-1.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
CURSOR
f
/
d
" button is pressed.
Press the "
ENTER
" button to set the currently displayed mode and restart the device.
q
L1
–1.SERVICE CHECK
L2
2.PROTECTION
Service Path Check Mode：See "DIAGNOSTIC MODE"
The Video and Audio paths can be checked.
This function is convenient for conrming problem paths in the product and checking the
paths after repairing.
w
L1
1.SERVICE CHECK
L2
–2.PROTECTION
The protection history can be checked.
e
L1
2.PROTECTION
L2
–3.RS232C RESET
Switches from 232C standby mode to normal standby mode.
r
L1
3.RS232C RESET
L2
–4.OP INFO
Operation Info for the unit can be checked.
t
(E3 Only)
L1
4.OP INFO
L2
–5.TUNER FRQ SET
Enables reception STEP of the ANALOG TUNER to be changed.
y
L1
5.TUNER FRQ SET
L2
–6.REMOTE ID
This function is for operating only the desired AV receiver.
3-1.4. Canceling the selected mode
Press the power button to turn off the power.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
143

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
