Denon AVR-X8500H Service Manual

3-4. Operation Info Mode
3-4.1. Actions
This mode enables the unit to display the accumulated operating time, power On count and each pro-
tection count.
3-4.2. Starting up
While holding down buttons "
ZONE3 SOURCE
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
Select the "
4. OP INFO
" using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to conrm.
3-4.3. Operations
Press the "
STATUS
" button after starting up this device in Operation Info mode.
The following information is displayed in the following order.
(1) Accumulated operating time
L1
Operation Time
L2
Total: ______H
↑ Time display
"
STATUS
"
(2) Power On time
L1
Power On Time
L2
Total: ______H
↑ Time display
"
STATUS
"
(3) DC / ASO Protection time
L1
Protection Time
L2
DC:___/ASO:___
"
STATUS
"
(4) Thermal Protection (H) count
L1
Protection Time
L2
THM H:___
"
STATUS
"
(5) Current Protection time
L1
Protection Time
L2
Current:___
"
STATUS
"
(Returns to normal display)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
146

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
