Denon AVR-X8500H Service Manual

RCKSK0410420 0 0 1 0 0 1 0 1 1 0 * * * * * * * * * * TFR LEVEL DOWN
RCKSK0410421 1 0 1 0 0 1 0 1 1 0 * * * * * * * * * * TML LEVEL UP
RCKSK0410422 0 1 1 0 0 1 0 1 1 0 * * * * * * * * * * TML LEVEL DOWN
RCKSK0410423 1 1 1 0 0 1 0 1 1 0 * * * * * * * * * * TMR LEVEL UP
RCKSK0410424 0 0 0 1 0 1 0 1 1 0 * * * * * * * * * * TMR LEVEL DOWN
RCKSK0410425 1 0 0 1 0 1 0 1 1 0 * * * * * * * * * * TRL LEVEL UP
RCKSK0410426 0 1 0 1 0 1 0 1 1 0 * * * * * * * * * * TRL LEVEL DOWN
RCKSK0410427 1 1 0 1 0 1 0 1 1 0 * * * * * * * * * * TRR LEVEL UP
RCKSK0410428 0 0 1 1 0 1 0 1 1 0 * * * * * * * * * * TRR LEVEL DOWN
RCKSK0410429 1 0 1 1 0 1 0 1 1 0 * * * * * * * * * * RHL LEVEL UP
RCKSK0410430 0 1 1 1 0 1 0 1 1 0 * * * * * * * * * * RHL LEVEL DOWN
RCKSK0410431 1 1 1 1 0 1 0 1 1 0 * * * * * * * * * * RHR LEVEL UP
RCKSK0410432 0 0 0 0 1 1 0 1 1 0 * * * * * * * * * * RHR LEVEL DOWN
RCKSK0410433 1 0 0 0 1 1 0 1 1 0 * * * * * * * * * * FDL LEVEL UP
RCKSK0410434 0 1 0 0 1 1 0 1 1 0 * * * * * * * * * * FDL LEVEL DOWN
RCKSK0410435 1 1 0 0 1 1 0 1 1 0 * * * * * * * * * * FDR LEVEL UP
RCKSK0410436 0 0 1 0 1 1 0 1 1 0 * * * * * * * * * * FDR LEVEL DOWN
RCKSK0410437 1 0 1 0 1 1 0 1 1 0 * * * * * * * * * * SDL LEVEL UP
RCKSK0410438 0 1 1 0 1 1 0 1 1 0 * * * * * * * * * * SDL LEVEL DOWN
RCKSK0410439 1 1 1 0 1 1 0 1 1 0 * * * * * * * * * * SDR LEVEL UP
RCKSK0410440 0 0 0 1 1 1 0 1 1 0 * * * * * * * * * * SDR LEVEL DOWN
RCKSK0410441 1 0 0 1 1 1 0 1 1 0 * * * * * * * * * * BDL LEVEL UP
RCKSK0410442 0 1 0 1 1 1 0 1 1 0 * * * * * * * * * * BDL LEVEL DOWN
RCKSK0410443 1 1 0 1 1 1 0 1 1 0 * * * * * * * * * * BDR LEVEL UP
RCKSK0410444 0 0 1 1 1 1 0 1 1 0 * * * * * * * * * * BDR LEVEL DOWN
RCKSK0410445 1 0 1 1 1 1 0 1 1 0 * * * * * * * * * * Audyssey LFC ON
RCKSK0410446 0 1 1 1 1 1 0 1 1 0 * * * * * * * * * * Audyssey LFC OFF
RCKSK0410456 0 0 0 1 0 0 1 1 1 0 * * * * * * * * * * Audyssey LFC ON/OFF
RCKSK0410522 0 1 0 1 0 0 0 0 0 1 * * * * * * * * * * FRONT SPEAKER
RCKSK0410542 0 1 1 1 1 0 0 0 0 1 * * * * * * * * * * DYNAMIC VOLUME OFF
RCKSK0410545 1 0 0 0 0 1 0 0 0 1 * * * * * * * * * * DYNAMIC VOLUME SELECT
RCKSK0410547 1 1 0 0 0 1 0 0 0 1 * * * * * * * * * * DYNAMIC EQ SELECT
RCKSK0410548 0 0 1 0 0 1 0 0 0 1 * * * * * * * * * * AUDIO RESTORER SELECT
RCKSK0410549 1 0 1 0 0 1 0 0 0 1 * * * * * * * * * * DYNAMIC EQ/VOLUME SELECT
RCKSK0410556 0 0 1 1 0 1 0 0 0 1 * * * * * * * * * * RESTORER(OFF)
RCKSK0410557 1 0 1 1 0 1 0 0 0 1 * * * * * * * * * * RESTORER(High)
RCKSK0410558 0 1 1 1 0 1 0 0 0 1 * * * * * * * * * * RESTORER(Medium)
RCKSK0410559 1 1 1 1 0 1 0 0 0 1 * * * * * * * * * * RESTORER(Low)
RCKSK0410605 1 0 1 1 1 0 1 0 0 1 * * * * * * * * * * FRONT SP A ON/OFF
RCKSK0410606 0 1 1 1 1 0 1 0 0 1 * * * * * * * * * * FRONT SP B ON/OFF
RCKSK0410620 0 0 1 1 0 1 1 0 0 1 * * * * * * * * * * AUDIO DELAY MODE
RCKSK0410621 1 0 1 1 0 1 1 0 0 1 * * * * * * * * * * AUDIO DELAY UP
RCKSK0410622 0 1 1 1 0 1 1 0 0 1 * * * * * * * * * * AUDIO DELAY DOWN
RCKSK0410624 0 0 0 0 1 1 1 0 0 1 * * * * * * * * * * INFO
RCKSK0410640 0 0 0 0 0 0 0 1 0 1 * * * * * * * * * * FLD STATUS
RCKSK0410649 1 0 0 1 0 0 0 1 0 1 * * * * * * * * * * FHL LEVEL UP
RCKSK0410650 0 1 0 1 0 0 0 1 0 1 * * * * * * * * * * FHL LEVEL DOWN
RCKSK0410651 1 1 0 1 0 0 0 1 0 1 * * * * * * * * * * FHR LEVEL UP
RCKSK0410652 0 0 1 1 0 0 0 1 0 1 * * * * * * * * * * FHR LEVEL DOWN
RCKSK0410656 0 0 0 0 1 0 0 1 0 1 * * * * * * * * * * Front Display(Dimmer)
RCKSK0410669 1 0 1 1 1 0 0 1 0 1 * * * * * * * * * * HDMI Monitor Select 1
RCKSK0410670 0 1 1 1 1 0 0 1 0 1 * * * * * * * * * * HDMI Monitor Select 2
RCKSK0410671 1 1 1 1 1 0 0 1 0 1 * * * * * * * * * * HDMI Monitor Select Auto(Dual)
RCKSK0410691 1 1 0 0 1 1 0 1 0 1 * * * * * * * * * * Internet Radio
RCKSK0410698 0 1 0 1 1 1 0 1 0 1 * * * * * * * * * * CD / PHONO
RCKSK0410699 1 1 0 1 1 1 0 1 0 1 * * * * * * * * * * Media Server
RCKSK0410704 0 0 0 0 0 0 1 1 0 1 * * * * * * * * * * PHONO
RCKSK0410705 1 0 0 0 0 0 1 1 0 1 * * * * * * * * * * TUNER
RCKSK0410706 0 1 0 0 0 0 1 1 0 1 * * * * * * * * * * CD
RCKSK0410711 1 1 1 0 0 0 1 1 0 1 * * * * * * * * * *
HEOS MUSIC
RCKSK0410715 1 1 0 1 0 0 1 1 0 1 * * * * * * * * * * TUNER
RCKSK0410716 0 0 1 1 0 0 1 1 0 1 * * * * * * * * * *
HEOS MUSIC
RCKSK0410718 0 1 1 1 0 0 1 1 0 1
* * * * * * * * * * USB
RCKSK0410719 1 1 1 1 0 0 1 1 0 1 * * * * * * * * * * TUNER
RCKSK0410720 0 0 0 0 1 0 1 1 0 1 * * * * * * * * * * DVD
RCKSK0410721 1 0 0 0 1 0 1 1 0 1 * * * * * * * * * * Blu-ray
RCKSK0410722 0 1 0 0 1 0 1 1 0 1 * * * * * * * * * * TV AUDIO
RCKSK0410723 1 1 0 0 1 0 1 1 0 1 * * * * * * * * * * CBL/SAT
RCKSK0410725 1 0 1 0 1 0 1 1 0 1 * * * * * * * * * * GAME
RCKSK0410726 0 1 1 0 1 0 1 1 0 1 * * * * * * * * * * MEDIA PLAYER
RCKSK0410729 1 0 0 1 1 0 1 1 0 1 * * * * * * * * * * AUX1
RCKSK0410730 0 1 0 1 1 0 1 1 0 1 * * * * * * * * * * AUX2
RCKSK0410732 0 0 1 1 1 0 1 1 0 1 * * * * * * * * * * DVD/Blu-ray
RCKSK0410735 1 1 1 1 1 0 1 1 0 1 * * * * * * * * * * MEDIA PLAYER
RCKSK0410736 0 0 0 0 0 1 1 1 0 1 * * * * * * * * * * MultEQ XT32
RCKSK0410741 1 0 1 0 0 1 1 1 0 1 * * * * * * * * * * INTERNET RADIO(Recent Play)
RCKSK0410746 0 1 0 1 0 1 1 1 0 1 * * * * * * * * * * DYNAMIC EQ ON
RCKSK0410747 1 1 0 1 0 1 1 1 0 1 * * * * * * * * * * DYNAMIC EQ OFF
RCKSK0410748 0 0 1 1 0 1 1 1 0 1 * * * * * * * * * * DYNAMIC VOLUME(Heavy)
RCKSK0410749 1 0 1 1 0 1 1 1 0 1 * * * * * * * * * * DYNAMIC VOLUME(Medium)
RCKSK0410750 0 1 1 1 0 1 1 1 0 1 * * * * * * * * * * DYNAMIC VOLUME(Light)
RCKSK0410751 1 1 1 1 0 1 1 1 0 1 * * * * * * * * * * Bluetooth
RCKSK0410752 0 0 0 0 1 1 1 1 0 1 * * * * * * * * * * RESOLUTION
RCKSK0410753 1 0 0 0 1 1 1 1 0 1 * * * * * * * * * * Monitor Select
RCKSK0410754 0 1 0 0 1 1 1 1 0 1 * * * * * * * * * * RESOLUTION(HDMI)
RCKSK0410757 1 0 1 0 1 1 1 1 0 1 * * * * * * * * * * ASPECT(16:9)
RCKSK0410758 0 1 1 0 1 1 1 1 0 1 * * * * * * * * * * ASPECT(4:3)
RCKSK0410760 0 0 0 1 1 1 1 1 0 1 * * * * * * * * * * Reference Level Offset (0dB) for Dynamic EQ
RCKSK0410761 1 0 0 1 1 1 1 1 0 1 * * * * * * * * * * Reference Level Offset (5dB) for Dynamic EQ
RCKSK0410762 0 1 0 1 1 1 1 1 0 1
* * * * * * * * * *
Reference Level Offset (10dB) for Dynamic
EQ
RCKSK0410763 1 1 0 1 1 1 1 1 0 1
* * * * * * * * * *
Reference Level Offset (15dB) for Dynamic
EQ
RCKSK0410787 1 1 0 0 1 0 0 0 1 1 * * * * * * * * * * INPUT SOURCE SELECT Right
RCKSK0410788 0 0 1 0 1 0 0 0 1 1 * * * * * * * * * * INPUT SOURCE SELECT Left
RCKSK0410789 1 0 1 0 1 0 0 0 1 1 * * * * * * * * * * Graphic EQ (toggle)
RCKSK0410791 1 1 1 1 1 0 0 0 1 1 * * * * * * * * * * Graphic EQ ON
RCKSK0410792 0 0 0 1 1 0 0 0 1 1 * * * * * * * * * * Graphic EQ OFF
RCKSK0410822 0 1 1 0 1 1 0 0 1 1 * * * * * * * * * * All Zone Stereo ON
RCKSK0410823 1 1 1 0 1 1 0 0 1 1 * * * * * * * * * * All Zone Stereo OFF
RCKSK0410826 0 1 0 1 1 1 0 0 1 1 * * * * * * * * * * HDMI(CEC)Control ON
RCKSK0410827 1 1 0 1 1 1 0 0 1 1 * * * * * * * * * * HDMI(CEC)Control OFF
RCKSK0410829 1 0 1 1 1 1 0 0 1 1 * * * * * * * * * * HDMI Audio Out Select
RCKSK0410830 0 1 1 1 1 1 0 0 1 1 * * * * * * * * * * HDMI Audio Out TV
RCKSK0410831 1 1 1 1 1 1 0 0 1 1 * * * * * * * * * * HDMI Audio Out AMP
RCKSK0410834 0 1 0 0 0 0 1 0 1 1 * * * * * * * * * * All Zone Stereo ON/OFF
RCKSK0410836 0 0 1 0 0 0 1 0 1 1 * * * * * * * * * * SLEEP MODE
RCKSK0410849 1 0 0 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select
RCKSK0410850 0 1 0 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select Auto
RCKSK0410851 1 1 0 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select Movie
RCKSK0410852 0 0 1 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select Game
RCKSK0410854 0 1 1 0 1 0 1 0 1 1 * * * * * * * * * * Vertical Stretch ON
RCKSK0410855 1 1 1 0 1 0 1 0 1 1 * * * * * * * * * * Vertical Stretch OFF
RCKSK0410857 1 0 0 1 1 0 1 0 1 1 * * * * * * * * * * Loudness Management ON/OFF
RCKSK0410861 1 0 1 1 1 0 1 0 1 1 * * * * * * * * * * Bass Sync Up
RCKSK0410862 0 1 1 1 1 0 1 0 1 1 * * * * * * * * * * Bass Sync Down
RCKSK0410872 0 0 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(toggle)
RCKSK0410873 1 0 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(OFF)
RCKSK0410874 0 1 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(ON)
RCKSK0410875 1 1 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(AUTO)
RCKSK0410896 0 0 0 0 0 0 0 1 1 1 * * * * * * * * * * SHL LEVEL UP
RCKSK0410897 1 0 0 0 0 0 0 1 1 1 * * * * * * * * * * SHL LEVEL DOWN
RCKSK0410898 0 1 0 0 0 0 0 1 1 1 * * * * * * * * * * SHR LEVEL UP
RCKSK0410899 1 1 0 0 0 0 0 1 1 1 * * * * * * * * * * SHR LEVEL DOWN
RCKSK0410900 0 0 1 0 0 0 0 1 1 1 * * * * * * * * * * TS LEVEL UP
RCKSK0410901 1 0 1 0 0 0 0 1 1 1 * * * * * * * * * * TS LEVEL DOWN
RCKSK0410902
0 1 1 0 0 0 0 1 1 1 * * * * * * * * * *
CH（Center Height） LEVEL UP
RCKSK0410903
1 1 1 0 0 0 0 1 1 1 * * * * * * * * * *
CH（
Center Height） LEVEL DOWN
RCKSK0410949 1 0 1 0 1 1 0 1 1 1 * * * * * * * * * * OPTION
RCKSK0410950 0 1 1 0 1 1 0 1 1 1 * * * * * * * * * * PAGE Previous
RCKSK0410951 1 1 1 0 1 1 0 1 1 1 * * * * * * * * * * PAGE Next
RCKSK0410956 0 0 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE REPEAT
RCKSK0410957 1 0 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE RANDOM/SHUFFLE
RCKSK0410958 0 1 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE USB DIRECT PLAY
RCKSK0410959 1 1 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE FAVORITE DIRECT PLAY
RCKSK0410970 0 1 0 1 0 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE TUNING UP ※NA only
RCKSK0410971 1 1 0 1 0 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE TUNING DOWN ※NA only
RCKSK0410972 0 0 1 1 0 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE PRESET CH UP ※NA only
RCKSK0410973 1 0 1 1 0 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE PRESET CH DOWN ※NA only
RCKSK0410976 0 0 0 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE Rewind
RCKSK0410977
1 0 0 0 1 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE BAND FM ※NA only
RCKSK0410978
0 1 0 0 1 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE BAND AM ※NA only
RCKSK0410979 1 1 0 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE Fast Forward
RCKSK0410983 1 1 1 0 1 0 1 1 1 1
* * * * * * * * * *
MAIN ZONE SEARH ※NA only
RCKSK0410992 0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE PLAY/PAUSE
RCKSK0410993 1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE STOP
RCKSK0410994 0 1 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE PAUSE
RCKSK0410995 1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE SKIP MINUS/ TUNING DOWN
RCKSK0410996 0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE SKIP PLUS/TUNING UP
RCKSK0410997 1 0 1 0 0 1 1 1 1 1
* * * * * * * * * *
MAIN ZONE TUNING ▼ ※NA only
RCKSK0410998 0 1 1 0 0 1 1 1 1 1
* * * * * * * * * *
MAIN ZONE TUNING ▲ ※NA only
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
71

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
