Denon AVR-X8500H Service Manual

ZONE2
REMOTE ID SET: 1
DENON CODE
Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4
3
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 1 1 0 0
REMOTE ID SET: 2-4
DENON CODE
Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4
4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 0 0 1 0
No. Data ID parity Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0430005 1 0 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE2 POWER ON/OFF
RCKSK0430006 0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE2 POWER ON
RCKSK0430007 1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE2 POWER OFF
RCKSK0430016 0 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY1
RCKSK0430017 1 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY2
RCKSK0430018 0 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY3
RCKSK0430019 1 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY4
RCKSK0430020 0 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY5
RCKSK0430021 1 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY6
RCKSK0430022 0 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY7
RCKSK0430023 1 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY8
RCKSK0430024 0 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY9
RCKSK0430025 1 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY0
RCKSK0430027
1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR UP
RCKSK0430028
0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR DOWN
RCKSK0430029
1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR LEFT
RCKSK0430030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR RIGHT
RCKSK0430031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 ENTER
RCKSK0430034
0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * ZONE2 RETURN
RCKSK0430036 0 0 1 0 0 1 0 0 0 0 * * * * * * * * * * ZONE2 MEMORY
RCKSK0430223 1 1 1 1 1 0 1 1 0 0 * * * * * * * * * * ZONE2 AUX3 (Additional Source)
RCKSK0430224 0 0 0 0 0 1 1 1 0 0 * * * * * * * * * * ZONE2 AUX4 (Additional Source)
RCKSK0430225 1 0 0 0 0 1 1 1 0 0 * * * * * * * * * * ZONE2 AUX5 (Additional Source)
RCKSK0430226 0 1 0 0 0 1 1 1 0 0 * * * * * * * * * * ZONE2 AUX6 (Additional Source)
RCKSK0430227 1 1 0 0 0 1 1 1 0 0 * * * * * * * * * * ZONE2 AUX7 (Additional Source)
RCKSK0430292 0 0 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 1
RCKSK0430293 1 0 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 2
RCKSK0430294 0 1 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 3
RCKSK0430295 1 1 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 4
RCKSK0430296 0 0 0 1 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 5
RCKSK0430368 0 0 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME UP
RCKSK0430369 1 0 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME DOWN
RCKSK0430370 0 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME MUTE
RCKSK0430370 1 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET(MUTE)
RCKSK0430372 0 0 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET1(0dB)
RCKSK0430373 1 0 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET2(-20dB)
RCKSK0430374 0 1 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET3(-40dB)
RCKSK0430691 1 1 0 0 1 1 0 1 0 1 * * * * * * * * * * ZONE2 Internet Radio
RCKSK0430692 0 0 1 0 1 1 0 1 0 1 * * * * * * * * * * Main Zone Source CALL
RCKSK0430698 0 1 0 1 1 1 0 1 0 1 * * * * * * * * * * ZONE2 CD / PHONO
RCKSK0430699 1 1 0 1 1 1 0 1 0 1 * * * * * * * * * * ZONE2 Media Server
RCKSK0430704 0 0 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 PHONO
RCKSK0430705 1 0 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 TUNER
RCKSK0430706 0 1 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 CD
RCKSK0430711 1 1 1 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 HEOS MUSIC
RCKSK0430715 1 1 0 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 TUNER
RCKSK0430716 0 0 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 HEOS MUSIC
RCKSK0430718 0 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 USB
RCKSK0430719 1 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 TUNER
RCKSK0430720 0 0 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 DVD
RCKSK0430721 1 0 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 Blu-ray
RCKSK0430722 0 1 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 TV AUDIO
RCKSK0430723 1 1 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 CBL/SAT
RCKSK0430725 1 0 1 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 GAME
RCKSK0430726 0 1 1 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 MEDIA PLAYER
RCKSK0430729 1 0 0 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 AUX1
RCKSK0430730 0 1 0 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 AUX2
RCKSK0430732 0 0 1 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 DVD/Blu-ray
RCKSK0430735 1 1 1 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 MEDIA PLAYER
RCKSK0430741 1 0 1 0 0 1 1 1 0 1 * * * * * * * * * * ZONE2 INTERNET RADIO(Recent Play)
RCKSK0430751 1 1 1 1 0 1 1 1 0 1 * * * * * * * * * * ZONE2 Bluetooth
RCKSK0430787 1 1 0 0 1 0 0 0 1 1 * * * * * * * * * * ZONE2 INPUT SOURCE SELECT Right
RCKSK0430788 0 0 1 0 1 0 0 0 1 1 * * * * * * * * * * ZONE2 INPUT SOURCE SELECT Left
RCKSK0430788 0 0 1 0 0 0 1 0 1 1 * * * * * * * * * * ZONE2 SLEEP
RCKSK0430950 0 1 1 0 1 1 0 1 1 1 * * * * * * * * * * ZONE2 PAGE Previous
RCKSK0430951 1 1 1 0 1 1 0 1 1 1 * * * * * * * * * * ZONE2 PAGE Next
RCKSK0430956 0 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 REPEAT
RCKSK0430957 1 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 RANDOM/SHUFFLE
RCKSK0430958 0 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 USB DIRECT PLAY
RCKSK0430959 1 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 FAVORITE DIRECT PLAY
RCKSK0430970
0 1 0 1 0 0 1 1 1 1 * * * * * * * * * *
ZONE2 TUNING UP ※NA only
RCKSK0430971
1 1 0 1 0 0 1 1 1 1 * * * * * * * * * *
ZONE2 TUNING DOWN ※NA only
RCKSK0430972
0 0 1 1 0 0 1 1 1 1 * * * * * * * * * *
ZONE2 PRESET CH UP ※NA only
RCKSK0430973
1 0 1 1 0 0 1 1 1 1 * * * * * * * * * *
ZONE2 PRESET CH DOWN ※NA only
RCKSK0430976 0 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 Rewind
RCKSK0430977
1 0 0 0 1 0 1 1 1 1
* * * * * * * * * *
ZONE2 BAND FM ※NA only
RCKSK0430978
0 1 0 0 1 0 1 1 1 1
* * * * * * * * * *
ZONE2 BAND AM ※NA only
RCKSK0430979 1 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 Fast Foward
RCKSK0430983
1 1 1 0 1 0 1 1 1 1 * * * * * * * * * *
ZONE2 SEARCH ※NA only
RCKSK0430992 0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PLAY/PAUSE
RCKSK0430993 1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 STOP
RCKSK0430994 0 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PAUSE
RCKSK0430995 1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP MINUS/TUNING DOWN
RCKSK0430996 0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP PLUS/TUNING UP
RCKSK0430997
1 0 1 0 0 1 1 1 1 1 * * * * * * * * * *
ZONE2 TUNING ▼ ※NA only
RCKSK0430998
0 1 1 0 0 1 1 1 1 1 * * * * * * * * * *
ZONE2 TUNING ▲ ※NA only
ZONE3
REMOTE ID SET: 1
DENON CODE
Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4
5
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 1 1 0 0
REMOTE ID SET: 2-4
DENON CODE
Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4
6
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 0 0 1 0
No. Data ID parity Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0450005 1 0 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE3 POWER ON/OFF
RCKSK0450006 0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE3 POWER ON
RCKSK0450007 1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE3 POWER OFF
RCKSK0450016 0 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY1
RCKSK0450017 1 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY2
RCKSK0450018 0 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY3
RCKSK0450019 1 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY4
RCKSK0450020 0 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY5
RCKSK0450021 1 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY6
RCKSK0450022 0 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY7
RCKSK0450023 1 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY8
RCKSK0450024 0 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY9
RCKSK0450025 1 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY0
RCKSK0450027
1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR UP
RCKSK0450028
0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR DOWN
RCKSK0450029
1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR LEFT
RCKSK0450030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR RIGHT
RCKSK0450031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 ENTER
RCKSK0450034
0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * ZONE3 RETURN
RCKSK0450036 0 0 1 0 0 1 0 0 0 0 * * * * * * * * * * ZONE3 MEMORY
RCKSK0450223 1 1 1 1 1 0 1 1 0 0 * * * * * * * * * * ZONE3 AUX3 (Additional Source)
RCKSK0450224 0 0 0 0 0 1 1 1 0 0 * * * * * * * * * * ZONE3 AUX4 (Additional Source)
