Vertical placement
When placing this unit vertically, attach the stand for vertical placement
to this unit with the power button in the upper position as shown in the
diagram.
2 How to attach the stand for vertical placement
q Align the rear edge of this unit to the guide position.
w Press down this unit onto the stand until it clicks.
e Slide this unit in the arrow direction to align the edge of this unit
with that of the stand.
q
w
e
Guide
Guide
•To remove the stand from this unit, follow the above steps for attaching
the stand in the reverse order.
