Specifications
2 Audio performance [DSD signal] [PCM signal]
•Analog output
Channels: 2 channels 2 channels
Playable frequency range: 2 Hz – 100 kHz 2 Hz – 96 kHz
Playable frequency response: 2 Hz – 50 kHz (–3 dB) 2 Hz – 20 kHz (±0.5 dB)
S/N: 112 dB (Audible range) 112 dB
Dynamic range: 105 dB (Audible range) 105 dB
Harmonic distortion: 0.0018 % (1 kHz, Audible range) 0.0018 % (1 kHz)
Output level: 2.0 V (10 kΩ/kohms) 2.0 V (10 kΩ/kohms)
Sampling frequency: 2.8224/5.6448 MHz 32/44.1/48/64/88.2/96/176.4/192 kHz
•Digital input
Format: Digital audio interface (Linear PCM)
Coaxial: 0.5 Vp-p / 75 Ω/ohms
Optical: –27 dBm or lator
Emission wavelength: 660 nm
2 General
AC adapter: Input : 100 – 240 V, 50/60 Hz
Output : DC 15 V, 1 A
For purposes of improvement, specifications and design are subject to change without notice.
