Denon DCD-710AE - DISASSEMBLY PROCEDURES; Disassembly Flow Overview

5
DCD-710AE
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
• In the case of the re-assembling, observe "attention of assembling" it.
About the photos used for descriptions in the “DISASSEMBLY” section.
• The direction from which the photographs used herein were photographed is indicated at "Direction of photograph: ***" at
the left of the respective photographs.
• Refer to the table below for a description of the direction in which the photos were taken.
• Photographs for which no direction is indicated were taken from above the product.
TOP COVER
DOOR CD MECHANISM ASSY AUDIO/POWER PCB
Refer to "DISASSEMBLY 1.DOOR" Refer to "DISASSEMBLY Refer to "EXPLODED VIEW"
Refer to "EXPLODED VIEW" 3.CD MECHANISM ASSY" AUDIO/POWER PCB
DOOR Refer to "EXPLODED VIEW" (Ref. No. of EXPLODED VIEW : 1-1)
(Ref. No. of EXPLODED VIEW : 9) CD MECHANISM ASSY
(Ref. No. of EXPLODED VIEW : 16)
FRONT PANEL ASS
Y
REAR PANE
L
Refer to "DISASSEMBLY 2.FRONT PANEL ASSY" MAIN PCB ASS
Y
Refer to "EXPLODED VIEW"
Refer to "EXPLODED VIEW" Refer to "EXPLODED VIEW" REAR PANEL
DISPLAY PCB MAIN PCB ASSY (Ref. No. of EXPLODED VIEW : 12)
(Ref. No. of EXPLODED VIEW : 1-2) (Ref. No. of EXPLODED VIEW : 2)
H/P PCB
(Ref. No. of EXPLODED VIEW : 1-3)
MOMS PCB
POWER TRANS
(Ref. No. of EXPLODED VIEW : 1-4) Refer to "EXPLODED VIEW"
USB PCB POWER TRANS
(Ref. No. of EXPLODED VIEW : 1-5) (Ref. No. of EXPLODED VIEW : 21)
LED PCB
(Ref. No. of EXPLODED VIEW : 1-6)
The viewpoint of each photograph
(photography direction)
［View from above］
Front side
Direction of photograph: A
