Denon DCD-710AE - MEASURING POINTS AND WAVEFORMS; Main PCB Assembly Layouts

33
DCD-710AE
MEASURING POINT AND WAVEFORMS
MEASURING POINT
CUP12202 MAIN PCB ASSY (Component side)
CUP12202 MAIN PCB ASSY (Foil side)
w RFOq RFEQO
o OPSW
Q0 CLSW
u FMO
i DMO
r FOO
y TRO
Q2 LOAD-
Q1 LOAD+
e FSMONIT
(IC17 : 21pin)
t TEI
(IC17 : 24pin)
