67
DCD-710AE
PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate he following destinations.
E2 : Europe model E1C : China model
BK : (Black model SP : (Premium Silver model
Ref No. Part No. Part Name Remarks Q'ty New
1 nsp AUDIO/POWER PCB ASSY CUP12201B 1*
1-1 - AUDIO/POWER PCB
1-2 - DISPLAY PCB
1-3 - H/P PCB
1-4 - MOMS PCB
1-5 - USB PCB
1-6 - LED PCB
2 nsp MAIN PCB ASSY
CUP12202B 1*
3 943402006350D FRONT PANEL BKE2
CKM1A213YC45 1*
3 943402006360D FRONT PANEL SPE2/SPE1C
CKM1A213ZC62 1*
4 943443006390D INNER PANEL BKE2
CGW1A480B28 1*
4 943443006400D INNER PANEL SPE2/SPE1C
CGW1A480RGG45 1*
4-1 - KNOB GUIDE
CGW1A480-1 1
4-2 - KNOB GUIDE
CGW1A480-2 1
4-3 - KNOB GUIDE
CGW1A480-3 1
5 00D9430189903 LENS
CGL1A254 1
6 00D1310158049 DENON BADGE BKE2
CGB1A140U 1
6 00D1310158052 DENON BADGE SPE2/SPE1C
CGB1A140T 1
7 00D9430179502 POWER KNOB BKE2
CGK1A124ZA 1
7 00D9430179609 POWER KNOB SPE2/SPE1C
CGK1A124YA 1
8 943416006410D FIP WINDOW
CGU1A397Y 1*
9 00D9430180708 DOOR BKE2
CGR2A404WB28 1
9 00D9430180805 DOOR SPE2/SPE1C
CGR2A404RGYG45 1
10 00D9430180902 LEVEL KNOB BKE2
CBC1A157B28 1
10 00D9430181008 LEVEL KNOB SPE2/SPE1C
CBC1A157RGG45 1
11 nsp BOTTOM CHASSIS
CUA5A269 1*
12 943406006670D REAR PANEL E2
CKF3A316Z 1*
12 943406006680D REAR PANEL E1C
CKF3A316X 1*
13 nsp FOOT
CKL1A093 4
14 nsp FOOT CUSHION
CHG2A289 4
15 nsp MECHA SUPPORT
CMH2A259 4
16 943302000090D CD MECHANISM ASSY
CJDWSL11TCNA 1
17 nsp PCB HOLDER
CHE170 2
18 nsp PCB HOLDER
CHE2A030 3
19 00D9430180407 AC CORD E2
CJA2B043ZA 1
19 943611006700S AC CORD E1C
CJA2N047ZA 1
20 00D9430095505 AC CORD BUSHING
KHR1A028 1
21 943101006510D POWER TRANSFORMER
CLT5M039ZE 1*
22 00D9430181105 TOP COVER BKE2
CKC1A175S56 1
22 00D9430181202 TOP COVER SPE2/SPE1C
CKC1A175S55 1
23 nsp EARTH PLATE
CMC1A369 1*
24 nsp RUBBER
CHG1A113 3
25 nsp SERIAL NO LABEL
CQB1A622 1
27 00D9430201000 FERRITE CORE
CLZ9W003Z 1
28 nsp HEMELON TAPE
CHS1A032 5
29 nsp CLAMPER
CHR301 5
z 30 00D9430140609 CSH1A010ZV(SDL1P-B)
CSH1A010ZV 1
