Denon DCD-710AE - PARTS LIST OF CD MECHANISM UNIT

70
DCD-710AE
PARTS LIST OF CD MECHANISM UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.\
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Q'ty New
1 00DS264629001 Tray (C) 1
2 - - This part (No.2)doesn't belong to the tray. Take it
down from old tray and use again when chang-
ing the tray.
3 00DS262554401 Gear cover(S) 1
4 00DS262553501 Tray gear(S) 1
5 00DS262554601 Chucking plate 1
6 nsp Screw 2.6 x 7 +PTPWH 4
7 nsp Chucking yoke 1
8 nsp Magnet 1
9 00D9640011007 MECHA DA11T3CN 1
10 nsp Chucking pulley 1
11 nsp Sub chassis Ass'y 1
12-1 00DS262723601 Coil spring(front) 2
12-2 00DS262723501 Coil spring(back) 2
13 nsp Screw 2.6 x 10 +P No slit type2 4
14 nsp Washer 2130 4
17 nsp Outsert main chassis(S) 1
18 nsp Screw 2.6 x 16 +PTPWH 1
19 00DS262554701 Drive gear(S) 1
20 00DS262554504 Contorol cam(S) 1
21 00DS169266711 Leaf switch 2
22 nsp 5P connector 1
23 nsp Loading P.W.B 1
24 00DSX26251171 Loading motor Ass'Y 1
25 00DS262553402 Middle gear 1
26 00DS262553602 Loading pulley 1
27 00DS365338700 LM belt 1
28 nsp Screw 2.6 x 2.5 +B 1
30 00DS262723401 Insulator 4
