Denon DCD-710AE - 2. Front Panel Assembly Disassembly

7
DCD-710AE
2. FRONT PANEL ASSY
(1) Remove the screws.
(2) Cut the clamp bands, disconnect the connector wires and FFC Cable Remove the screws..
TOP COVER
DOOR
→
FRONT PANEL ASSY
→
Proceeding :
View from bottom
cut
CX73
BN31
FFC Cable BN33
CN51
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in FRONT PANEL ASSY.
