Ref. No. Part No. Part Name Remarks Q'ty New
C958-963 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C964 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C965 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C966 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C967-969 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C970 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C971,972 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C973,974 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C975 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BD61-63 nsp CHIP FERRITE BEAD(60ohm 2012) CLZ9R001Z
BD71,72 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
BD81 nsp CHIP FERRITE BEAD(60ohm 2012) CLZ9R001Z
BD83 nsp CHIP,BEAD HLZ9Z008Z
BD91-95 nsp CHIP FERRITE BEAD(60ohm 2012) CLZ9R001Z
BK61 nsp PCB BRACKET CMD1A569
BN12 nsp WIRE ASS'Y (5P, 100MM) CWB1C005100G7
CN1A nsp WAFER FPC 23P 1.25mm CJP23GA285ZN
CN42,43 nsp
LOCKING TYPE, STRAIGHT WAFER
2MM
CJP15GI236ZW
CN71 nsp LOCKINGTYPE STRAIGHTWAFER 2MM CJP03GI236ZW
CN8A nsp WAFER CARD CABLE 23P, 1.0MM CJP23GA193ZY
CN91 nsp WAFER CARD CABLE 7P 1.25MM CJP07GB113ZY
CN9A nsp WAFER CARD CABLE 13P 1.25MM CJP13GA115ZY
ET71 nsp EARTH PALTE HJT1A025
ET91 nsp EARTH PALTE HJT1A025
JK62 943643010170S JACK NOSPCC6PWWW/RRR CJJ4R019T
JK71 943643010180S JACK NOSPCC2PY/Y CJJ4N092U
JK72 943643010190S JACK NOSPCCRCA/SVIDEO CJJ9N004U
JK81 943643010210S JACK ASS'Y CJS9U017Z+HJSTORX177L HJSTORX177L
JK82 943643100030S JACK RCA CJJ4M044X *
JK91 943643010220S JACK 3.5PIHORIZONTALWITHOUTRING CJJ2E033Z
L601,602 943115010270S MPX COIL(FM19KHzFILTER) CLM4B001Z
TU61 943183010320S
TUNER(USA)FM(SCREW:FTYPE)
,AM(S/LAB)
E3 CNVMW004MV1S63SN
TU61 943183010310S TUNER(EUR)FM,AM,RDS(S/LAB) E2,E1C,EA CNVMW104MV1S63N
X801 943141010360S CRYSTAL 24.576MHz 15PF 30PPM HOX24576E150TF
X901 943141010370S CRYSTAL 10.000MHz 22PF 30PPM HOX10000E220TF

Denon DHT-1312XP Specifications

General

Product color	Black
Volume control	Rotary
RMS rated power	110 W
Recommended usage	Home theatre
Remotely operated	Yes
Audio output channels	5.1 channels
Amplification device type	AV receiver
Amplifier frequency range	10 - 100000 Hz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Amplification device form factor	Stand-alone
Amplifier dimensions (W x D x H)	434 x 382 x 162 mm
Satellite speaker type	-
Satellite speaker weight	800 g
Number of satellite speakers	2
Satellite speakers RMS power	- W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker dimensions (WxDxH)	105 x 150 x 200 mm
Center speaker dimensions (WxDxH)	200 x 150 x 105 mm
Subwoofer weight	11000 g
Subwoofer frequency range	35 - 150 Hz
Subwoofer dimensions (WxDxH)	250 x 420 x 387 mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Headphone outputs	1

Weight and Dimensions

Set weight	8900 g
