27
(32) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
H H H H
(33) Press the "RESET" switch of “Writing Kit".
(34) Initializing.
1. Turn off the power using ON/STANDBY button.
2. Press ON/STANDBY button while simultaneously pressing DOCK CONTROL
8
and DOCK CONTROL
9
buttons.
3. Check that the entire display is ashing with an interval of about 1 second, and release your ngers from the 2
buttons and the microprocessor will be initialized.
3. Notice:
Please keep the following notice for rmware update.
(a) Keep the PC environment
(b) Avoid the communication cable from the electrical noise source.
(e.g. telephone cable, AC line, a uorescent light)
(c) Don’t remove cable during update.
(d) Don’t turn off the power during update.
(e) Don’t run other PC application during update.
(f) Stop the resident program on PC (Virus checker and System check utilitu, etc)
(g) Stop the screen saver on PC.
(h) Stop the power save ability on PC.
(i) In case of laptop PC, Use the AC adaptor.
Conrmingthermware’snumberafterupgraded
After completion of the updating operation, the new version number can conrmed by starting up the AVR-1312 according
to the following procedure.
With the following operation, the AVR-1312 can be set to the Flash ROM Version-Number Conrmation mode.
Turn on power switch while simultaneously pressing "DIMMER" and "STATUS" buttons on the front panel. Every time the
"STATUS" button is pressed, version number of the Model, Main, DSP, … are indicated on the front panel section. (Refer
to "1.2. Display other" (page 14 ))
Note: • If step 3 does not work, start over from step 1.
• All user settings will be lost and this factory setting will be recovered when this initialization mode.
So make sure to memorize your setting for restoring after the initialization.
