Denon DHT-1312XP User Manual

94
Ref. No. Part No. Part Name Remarks Q'ty New
R532 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT *
R533-537 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R538 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R539-542 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R543-546 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R547-554 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R559 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R563 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R564 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT
R577 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R616 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R618 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R619 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R621 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R625-628 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT *
R630 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R632 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R634,635 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT *
VR41-45 nsp RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
CAPACITORS GROUP
C403 943134010660S ELECT CAP 470UF 6.3V CCEA0JH471T
C404-407 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C408 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C409 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C410 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C411 nsp CERAMIC CAP 100PF 50V KB E3 CCKT1H101KB
C411 nsp CERAMIC CAP 82PF 50V J E2,E1C,EA CCCT1H820JC
C412 nsp CERAMIC CAP 100PF 50V KB E3 CCKT1H101KB
C412 nsp CERAMIC CAP 82PF 50V J E2,E1C,EA CCCT1H820JC
C413 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C414 nsp CERAMIC CAP 100PF 50V KB E3 CCKT1H101KB
C414 nsp CERAMIC CAP 82PF 50V J E2,E1C,EA CCCT1H820JC
C415 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C416-418 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C419 nsp FILM CAP 0.015UF 100V J MYLAR E3 HCQI1H153JZT
C419 nsp MYLAR CAP 0.018UF 100V J MYLAR E2,E1C,EA HCQI1H183JZT
C420 nsp FILM CAP 0.015UF 100V J MYLAR E3 HCQI1H153JZT
C420 nsp MYLAR CAP 0.018UF 100V J MYLAR E2,E1C,EA HCQI1H183JZT
C421 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C422 nsp CERAMIC CAP 100PF 50V KB E3 CCKT1H101KB
C422 nsp CERAMIC CAP 82PF 50V J E2,E1C,EA CCCT1H820JC
C423-426 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C427 943134010660S ELECT CAP 470UF 6.3V CCEA0JH471T
C428 943134010490S ELECT CAP 100UF 10V CCEA1AH101T
C429 nsp FILM CAP 0.015UF 100V J MYLAR E3 HCQI1H153JZT
C429 nsp MYLAR CAP 0.018UF 100V J MYLAR E2,E1C,EA HCQI1H183JZT
C430 nsp FILM CAP 0.015UF 100V J MYLAR E3 HCQI1H153JZT
C430 nsp MYLAR CAP 0.018UF 100V J MYLAR E2,E1C,EA HCQI1H183JZT
C431 nsp FILM CAP 0.015UF 100V J MYLAR E3 HCQI1H153JZT
C431 nsp MYLAR CAP 0.018UF 100V J MYLAR E2,E1C,EA HCQI1H183JZT
C432 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C433 nsp MYLAR CAP 2200PF 100V J E3 HCQI1H222JZT
C433 nsp MYLAR CAP 1000PF 100V J MYLAR E2,E1C,EA HCQI1H102JZT
C434 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C435 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C436 nsp MYLAR CAP 2200PF 100V J E3 HCQI1H222JZT
C436 nsp MYLAR CAP 1000PF 100V J MYLAR E2,E1C,EA HCQI1H102JZT
C437 nsp MYLAR CAP 2200PF 100V J E3 HCQI1H222JZT
C437 nsp MYLAR CAP 1000PF 100V J MYLAR E2,E1C,EA HCQI1H102JZT
C438 nsp MYLAR CAP 2200PF 100V J E3 HCQI1H222JZT
C438 nsp MYLAR CAP 1000PF 100V J MYLAR E2,E1C,EA HCQI1H102JZT
C439 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C440 nsp MYLAR CAP 2200PF 100V J E3 HCQI1H222JZT
C440 nsp MYLAR CAP 1000PF 100V J MYLAR E2,E1C,EA HCQI1H102JZT

Denon DHT-1312XP Specifications

General

Product color	Black
Volume control	Rotary
RMS rated power	110 W
Recommended usage	Home theatre
Remotely operated	Yes
Audio output channels	5.1 channels
Amplification device type	AV receiver
Amplifier frequency range	10 - 100000 Hz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Amplification device form factor	Stand-alone
Amplifier dimensions (W x D x H)	434 x 382 x 162 mm
Satellite speaker type	-
Satellite speaker weight	800 g
Number of satellite speakers	2
Satellite speakers RMS power	- W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker dimensions (WxDxH)	105 x 150 x 200 mm
Center speaker dimensions (WxDxH)	200 x 150 x 105 mm
Subwoofer weight	11000 g
Subwoofer frequency range	35 - 150 Hz
Subwoofer dimensions (WxDxH)	250 x 420 x 387 mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Headphone outputs	1

Weight and Dimensions

Set weight	8900 g
