Remote Control Unit
q INPUT buttons ··········································(10)
w MODE SELECT buttons ····························(10)
e NIGHT MODE button ································(10)
r SDB button ················································(10)
t VOLUME buttons ······································(10)
y ON/STANDBY button ·································(9)
u MUTE button ············································(10)
i SETUP button ·············································(9)
Installation
Select one of the two ways of installing the speaker unit.
Mount the feet in the screw holes in the unit’s bottom panel.
<View from the side>
Front speaker unit
TV’s base
2.1 ft / 629 mm
2.1 ft / 629 mm
About the Installation
Horizontally
• When using screw type feet, the base of flat TV
can be placed in the spaces on the bottom of the
DHT-FS5.
• Depending on the TV’s shape, it may not be
possible to install as shown in the picture.
• Be careful that the DHT-FS5 does not obstruct the
TV’s remote control sensor.
• If color blotching occurs on a Braun tube TV or
Braun tube monitor, move the DHT-FS5 as far
away from the TV or monitor as possible.
NOTE
Be sure to mount the same type of feet in all four
holes so that the unit remains level.
Getting Started Installation
To Next Page
