Denon DRA-397 - Parts List of Exploded View

48
DRA-397/297/37
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Ref. No. nsp Part No. Part Name Remarks Q'ty New
44A - MAIN P.W.B. UNIT ASSY for 397
7025HK0604010 1
43A - MAIN P.W.B. UNIT ASSY for 297
7025HK0603010 1
43A - MAIN P.W.B. UNIT ASSY for 37
7025HK0603040 1
13 P.C.B FUNCTION UNIT for 297, 397
! 15 P.C.B POWER SW UNIT
43 P.C.B MAIN UNIT
57 P.C.B VIDEO UNIT
22A - FRONT P.W.B. UNIT ASSY for 397
7025HK0604011 1
21A - FRONT P.W.B. UNIT ASSY for 297
7025HK0603011 1
21A - FRONT P.W.B. UNIT ASSY for 37
7025HK0603041 1
14 P.C.B HEADPHONE UNIT
21 P.C.B FRONT UNIT
56 P.C.B PREOUT UNIT for 37
60 P.C.B CPU UNIT
62 P.C.B ZONE UNIT for 397
20A - FUNCTION P.W.B. UNIT ASSY for 37
7025HK0603044 1
20 P.C.B FUNCTION SW UNIT
25 P.C.B STANDBY SW UNIT
54 - XM-READY P.W.B. UNIT ASSY for 397
7025HK0604013 1
54 - XM-READY P.W.B. UNIT ASSY for 297
7025HK0603013 1
54 - XM-READY P.W.B. UNIT ASSY for 37
7025HK0603043 1
55 - INPUT P.W.B. UNIT ASSY for 397
7025HK0604012 1
55 - INPUT P.W.B. UNIT ASSY for 297
7025HK0603012 1
55 - INPUT P.W.B. UNIT ASSY for 37
7025HK0603042 1
59 - CNT P.W.B. UNIT ASSY for 397
7025HK0604014 1
59 - CNT P.W.B. UNIT ASSY for 297
7025HK0603014 1
59 - CNT P.W.B. UNIT ASSY for 37
7025HK0603045 1
1 00D 963 0304 203 PANEL FRONT for 397
3067212741000S 1*
1 00D 963 0304 300 PANEL FRONT for 297
3067212741100S 1*
1 00D 963 0316 107 PANEL FRONT for 37
3067212731000S 1*
2 00D 963 0051 501 BADGE DENON
5630210028000S 1
3 00D 963 0298 306 KNOB INPUT ASSY for 397
5088211278000SZ 1
3 00D 963 0138 301 KNOB INPUT for 297, 37
5087210961000S 1
4 00D 963 0305 600 WINDOW DISPLAY for 397
50772119220L0S 1*
4 00D 963 0305 503 WINDOW DISPLAY for 297
50772119220K0S 1*
4 00D 963 0316 408 WINDOW DISPLAY for 37
5077212283010S 1*
5 00D 963 0316 709 BUTTON 2KEY for 397
5097213171000S 1
6 00D 963 0298 209 KNOB VOLUME ASSY for 397
5088211268020SZ 1
6 00D 963 0138 806 KNOB VOLUME for 297, 37
5087210981000S 1
7 00D 963 0152 905 KNOB SELECT for 397
5087210958000SZ 1
7 00D 963 0138 505 KNOB SELECT for 297, 37
5087210971000S 1
8 nsp 00D 963 0138 000 BRACKET SIDE L/R
4010211986000S 2
9 00D 963 0137 807 LENS STANDBY
3710210503000S 1
10 00D 963 0184 106 BUTTON STANDBY
5097212368000SZ 1
11 00D 963 0184 009 BUTTON POWER
5097212358000SZ 1
12 00D 960 0191 417 LENS LED
3710210043001S 2
