Denon HEOS AVR Service Manual

CAUTION IN SERVICING
SAFETY PRECAUTIONS
NOTE FOR SCHEMATIC DIAGRAM
NOTE FOR PARTS LIST
INSTRUCTIONS FOR HANDLING SEMICONDUCTORS AND OPTICAL UNIT
Online Parts List
Accessing the Parts List
Logging in to New SDI and Accessing the Parts List
Accessing the Part List from the Model Asset Screen
PRINTED CIRCUIT BOARDS Parts Table
Downloading the Parts List as an Excel File
Revision History
Searching Part Numbers or Ref. Numbers
2
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon HEOS AVR Specifications

General

Receiver type	Surround
Frequency range	10 - 40000 Hz
Audio output channels	5.1 channels
Power output per channel (20-20KHz@8 Ohm)	50 W
Display	-
HDCP version	2.2
Product color	Black, Silver
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
Amplifier output power	100 W
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	110 W
HDMI in	4
Ethernet LAN (RJ-45) ports	1
Cables included	AC, HDMI, LAN (RJ-45), Optical
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Optical drive included	No
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Tidal, TuneIn
Connectivity technology	Wired & Wireless
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	265 mm
Width	434 mm
Height	91 mm
Weight	6000 g
