Denon MC4000 User Manual

VirtualDJ 8 – Denon MC4000
14
I. REAR PANEL
28. POWER: Use included power adapter (6V DC, 3A, center-positive) to connect
MC4000 to a power outlet. While the power is switched off, plug the cable into
MC4000 first, and then plug the other end into a power outlet. Use the Power Switch
to turn the MC4000 on and off. Turn on the MC4000 after all input devices have been
connected and before you turn on amplifiers. Turn off amplifiers before you turn off
the unit
29. USB. This USB connection sends and receives audio and control information from a
connected computer.
30. BOOTH OUTPUT (TRS): Use standard TRS cables to connect this output to a booth
monitoring system. The level of this output is controlled by the Booth knob on the top
panel.
31. MASTER OUTPUT (XLR): Connect this low-impedance XLR output to a PA system
or powered monitors. The level of this output is controlled with the Master knob on
the top panel.
32. MASTER OUTPUT (RCA): Use standard RCA cables to connect this output to a
speaker or amplifier system. The level of this output is controlled by the Master knob
on the top panel.
33. AUX. Use standard RCA cables to connect this input to an external analogue media
source (CD, MPE player etc). The level of this input is controlled by the AUX knob on
the top panel.
34. MIC2 INPUT. Connect a 1/4" microphone to this input.
35. MIC1 INPUT. Connect a 1/4" or a XLR microphone to this input.
J. FRONT PANEL

Denon MC4000 Specifications

General

MIDI	24 bit
Sample rate	48 kHz
Mixer section	Yes
Product color	Black
Frequency range	20 - 20000 Hz
Output level (XLR)	4 dBV
Built-in optical drive	-
Signal-to-Noise Ratio (SNR)	88 dB
Number of dedicated effects controls	2
Maximum output level (master, balanced, XLR)	24
Total Harmonic Distortion plus Noise (THD+N)	0.01 %
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Current	3 A
Input voltage	5 V
Power supply type	AC

Weight and Dimensions

Depth	312 mm
Width	505 mm
Height	69 mm
Weight	4060 g
Package weight	6000 g
