1. CROSSFADER. Blends audio
between the left and right decks
2. VOLUME. Use these faders to
adjust the Volume of each deck.
3. VU METERS The Led Meters
indicate the Output Level of each
deck
4. CUE/PFL. Press these buttons to
send this deck's pre-fader signal to
the Cue Channel for monitoring.
When engaged, the button will be
lit.
5. FILTER. Use these knobs to apply
a High/Low Pass Filter on the
left/right decks.
6. EQ LOW. Adjusts the low (bass)
frequencies of each deck.
7. EQ MID. Adjusts the middle (mid)
frequencies of each deck
8. EQ HIGH. Adjusts the high (treble)
frequencies of each deck
9. GAIN. Adjusts the audio level
(gain) of the corresponding deck
10. LOAD. Use these buttons to load the selected track from the Browser to the left or
right deck. Hold the same button for more than 2 seconds to unload the same deck.
Hold SHIFT down and then use these buttons to clone the deck to the opposite one.
11. LIBRARY. Use this encoder to scroll through Folders or Files. Hold SHIFT down and
use this encoder to scroll faster (+/- 10 tracks per step). Push the encoder to set
focus to the Songs List.
12. BACK Use this button to set focus to the Folders List. If the focus is on the Folders
list, use this button to expand/collapse sub-folders.
Hold SHIFT down and then use this button to cycle through the available center
panels of the default GUI of VirtualDJ (Mixer, Video, Scratch an Master view)
