Operation Section
1
–
44
Terminal Connections (2)
No. Pin Symbol Signal Name No. Pin Symbol Signal Name
A21 TWV4 Injection 4 Drive (#2 Cylinder) A57 — —
A22 TWV4 Injection 4 Drive (#2 Cylinder) A58 — —
A23 TWV2 Injection 2 Drive (#3 Cylinder) A59 — —
A24 TWV2 Injection 2 Drive (#3 Cylinder) A60 — —
A25 — — A61 — —
A26 A/C R Air Conditioning Relay A62 — —
A27 C FAN R FAN Relay A63 A-VCC5 Rail Pressure Sensor (PC Sensor)
Source
A28 — — A64 A-VCC6 Turbo Pressure Sensor Source (5V)
A29 SCV- SCV (Suction Control Valve) A65 NE- Crankshaft Position Sensor Ground
A30 TEST Test Switch Input A66 G- Cylinder Recognition Sensor Ground
A31 A/C2 SW Air Conditioning 2 Switch A67 — —
A32 — — A68 PFUEL RTN Rail Pressure Sensor Earth
A33 — — A69 THF RTN Air Temperature Sensor, Fuel Temper-
ature Sensor Earth
A34 — — A70 THW RTN Coolant Temperature Sensor Earth
A35 — — A71 BOOST RTN Turbo Pressure Sensor
A36 — — A72 EGR LIFT
RTS
EGR Position Sensor Earth
A37 GLOW R Glow Plug Relay A73 AMF-RTN Airflow Sensor Earth
A38 GLOW L Glow Light A74 EXT-A-RTN Air Temperature Sensor Earth
(W/FAS)
A39 — — A75 — —
A40 TWV3 Injection 3 Drive (#4 Cylinder) A76 — —
A41 TWV3 Injection 3 Drive (#4 Cylinder) A77 — —
A42 TWV1 Injection 1 Drive (#1 Cylinder) A78 — —
A43 TWV1 Injection 1 Drive (#1 Cylinder) A79 THA Air Temperature Sensor
A44 A-VCC3 Crankshaft Position Sensor BATT A80 — —
A45 A-VCC4 Cylinder Recognition Sensor BATT A81 ETCP-S Electoronic Throttle Control (Sub)
A46 NE+ Crankshaft Position Sensor B01 A-VCC 1 Accelerator Position Sensor (Main)
Source
A47 G+ Cylinder Recognition Sensor B02 APS 1 Accelerator Position Sensor (Main)
A48 PFUEL Rail Pressure Sensor (PC Sensor) B03 APS 1 GND Accelerator Position Sensor (Main)
Earth
A49 PFUEL Rail Pressure Sensor (B/UP) B04 — —
A50 THF Fuel Temperature Sensor B05 ETCP-M Electoronic Throttle Control (Main)
A51 THW Coolant Temperature Sensor B06 CAN1-L CAN L (W/Resister)
A52 BOOST Turbo Pressure Sensor B07 — —
A53 EGR LIFT EGR Position Sensor B08 — —
A54 AMF Airflow Sensor B09 A-VCC 2 Accelerator Position Sensor (Sub)
Source
A55 EXT-A-TMP Air Temperature Sensor (W/AFS) B10 APS 2 Accelerator Position Sensor (Sub)
To Next Page
