Terminal Connections (3)
No. Pin Symbol Signal Name No. Pin Symbol Signal Name
B11 APS 2 GND Accelerator Position Sensor (Sub)
Earth
B26 IG-SW Ignition Switch
B12 — — B27 — —
B13 — — B28 — —
B14 CAN1-H CAN H (W/Resister) B29 — —
B15 — — B30 PS-SW Power Steering Switch
B16 SPD Vehicle Speed Sensor B31 — —
B17 — — B32 — —
B18 STA-SW Starter Switch B33 C-GND Signal Ground
B19 MT 1ST SW 1st Shift Switch B34 — —
B20 MT REV SW Reverse Shift Switch B35 ETC+ Electronic Throttle Control Motor (+)
B21 — — B36 — —
B22 — — B37 ETC- Electronic Throttle Control Motor (-)
B23 — — B38 +BP Battery
B24 M-REL Control (ECCS) Relay (W/
DIODE)
B39 +BP Battery
B25 TACHO Tacho Meter B40 BATT Battery (Back-up, W/Monitor)
