Appendix A. Specifications
A.1 BHT-300B
[ 1 ] Product Specifications
Power Source Main power Rechargeable lithium-ion battery cartridge (3.7 VDC)
Dimensions (W) x (L) x (H)
70 x 182 x 55 mm (2.8 x 7.2 x 2.2 inches)
Weight Approx. 230 g (Approx. 8.19 oz.) including battery cartridge
Operating Ambient Temperature -5°C to 50°C (23°F to 122°F)
Operating Humidity 20% to 80% (with no dew condensation)
Ambient Illuminance 500 to 3000 lux.
(Depth of field: 45 mm, PCS value: 0.9 min., Reflection intensity:
85% min. for white and 5% max. for black, Narrow bar width:
0.125 mm min.)
20 to 10,000 lux.
(Depth of field: 100 mm, ITF: 0.625 magnification, PCS value:
0.9 min., Reflection intensity: 85% min. for white and 5% max. fo
r
black)
Controller CPU: 32-bit RISC
RAM: 1MB
Flash ROM: 4MB(BHT-302B) / 8MB(BHT-303B)
Keypad Magic keys: 4
Function keys: 8
Numerical keys and others: 16
Display Type: Dot-matrix, FSTN liquid crystal display (LCD) with
backlight
Formation: 132 dots wide by 72 dots high
Screen mode Font size Chars x Lines Dots (W x H)
Standard-size 22 x 9 6 x 8
Single-byte
ANK* mode
Small-size 22 x 12 6 x 6
Full-width 8 x 4 16 x 16
16-dot font
Half-width 16 x 4 8 x 16
Full-width 4 x 4 32 x 16
16-dot font
(Double-width)
Half-width 8 x 4 16 x 16
Full-width 11 x 6 12 x 12
12-dot font
Half-width 22 x 6 6 x 12
Full-width 5 x 6 24 x 12
Two-byte
Kanji mode
12-dot font
(Double-width)
Half-width 11 x 6 12 x 12
*ANK: Alphanumerics and Katakana
Calendar Clock Year, month, day, hour, minute, and second
Year: Two digits (with auto-correction on February 29 up to year
2099)
Reading Confirmation LED Colors: Red and green
EMC standard VCCI Class B
