Operation Section
1
–
8
(2) HP2 Type
• This system uses a type of HP2 supply pump that has been made lighter and more compact, and is the common rail
system for passenger cars and RVs instead of the ECD-V3.
Exterior View of Main System Components
Mounting Diagram of Main System Components
Q000757E
InjectorSupply Pump (HP2 Type)
Rail
Engine ECU
EDU (Electronic Driving Unit)
EGR Valve
E-VRV
Intake Air Temperature
Sensor
Intake Air Pressure Sensor
Injector
Crankshaft Position Sensor
(Engine Speed Sensor)
Rail
Supply Pump
Cylinder Recognition Sensor
(TDC (G) Sensor)
Rail Pressure Sensor
Accelerator Position Sensor
Coolant Temperature
Sensor
Q000758E
To Next Page
