Operation Section
1
–
9
Overall System Flow (Fuel)
Q000926E
Supply Pump
Plunger
Feed Pump
Delivery Valve
SCV
(Suction
Control
Valve)
Inner Cam
Regulating Valve
Check Valve
Rail
Rail Pressure Sensor
Pressure
Limiter
Injector
TWV
Engine
ECU
EDU
Various Sensors
Fuel Filter
Fuel Tank
: Flow of Injection Fuel
: Flow of Leak Fuel
