Denver CAT-140 - Page 6

E5
Locations of Parts (Main unit)
1. POWER ON/OFF ( ) / MUTE
2. SELECT FUNCTION BUTTON
3. PRESET STATIONS (1,2,3,4,5,6)
4. ‘AF’ FUNCTION BUTTON (ALTERNATIVE FREQUENCIES)
5. ‘TA’ FUNCTION BUTTON (TRAFFIC ANNOUNCEMENT)
6. ‘PTY’ FUNCTION (PROGRAM TYPE)
7. LOUDNESS BUTTON (LD)
8. MODE BUTTON (MD)
9. BAND BUTTON (BD)
10. CD TRACK / SEARCH BUTTON
11. AUTO SEEK TUNING
12. MUTE BUTTON (MU)
13. PANEL RELEASE BUTTON ( )
14. TFT-LCD DISPLAY
15. CD EJECT BUTTON ( )
16. TILT BUTTON
17. MENU BUTTON
18. FAST FORWARD / FAST REVERSE
19. STOP BUTTON
20. PLAY/PAUSE BUTTON
21. RESET BUTTON
22. CD SLOT
23. SD/MMC CARD SLOT
