(2) Fuel Level Indicator
That Indicates a fuel level in the fuel tank. All the lights are indicated green when the fuel
is full. The green lights stop indicating one by one as the fuel level decrease, finally the
red light will be indicated when it is only one green light is left. Replenish the tank when
there becomes only one lamp turned on. The table below shows the relation between
numbers of turn - on lamps and fuel level.
DCA-70ESEI DCA-125ESEI DCA-180ESEI Numbers of lamps
turned-on
Fuel level (L) Fuel level (L) Fuel level (L)
9 135 to full 215 to full 260 to full
8 120 to 135 190 to 215 235 to 260
7 105 to 120 165 to 190 200 to 235
6 90 to 105 145 to 165 170 to 200
5 75 to 90 120 to 145 145 to 170
4 60 to 75 100 to 120 115 to 145
3 50 to 60 85 to 100 100 to 115
2 40 to 50 65 to 85 75 to 100
1 0 to 40 0 to 65 0 to 75
(3) Alarm and Memory at Abnormal Condition
When any abnormal condition occurs in engine oil pressure, battery charging voltage,
or engine coolant temperature, the indication will change as the following;
1 - The Indicator shows its defect with blinking numbers.
2 - When the abnormal condition is corrected, the on - and - off indication will stop.
3 - If engine would stop urgently and automatically or stop manually with the abnormal
condition, the abnormal value will be memorized, and then indicated even after engine
is started again.
In this case, keep on pushing the button “RESET” for more than 5 seconds, and the
abnormal indication will be reset to normal.
(4) Hour Meter
① When you turn the starter switch to “RUN” position, and push the selector button located
on the right side of the Hour Meter, you can see the numbers mentioned below;
• “ODD” Total running hour
• “TRIP A” Running hours “A” on a certain period
• “TRIP B” Running hours “B” on a certain period
② If you want to reset the Trip Meters, push the selector button for more than 1 second,
after selecting each meters.
