- 24 -
②
When it is below the low limit, supply oil immediately.
③
t the same time, check condition of oil by the dipstick
2-4-2 Checking after installation
(1) Check engine oil
(Read the instruction manual for the engine furnished separately.)
①
Check the level of engine oil by the dipstick. Make sure the oil level
is always between H and L.
[ NOTE ]: Oil is consumed gradually during operation. When the ma-
chine is to be used continuously for a long time, be careful
with lack of oil.
(2) Check engine cooling water
(Read the instruction manual for the engine furnished separately.)
①
Check (to see) that cooling water in the reserve tank is within the
range of FULL-LOW.
②
When it is below the low limit, supply (additional) water immediately.
③
Normally, only the water level of the reserve tank needs to be
checked. But, the radiator cap should be opened once a week to
check that water is full in the radiator.
[ NOTE ]: When closing the radiator cap after water level is checked or
water is supplied, turn the cap fully clockwise so that it can be
firmly tightened.
Otherwise, cooling water is evaporated which results in serious
damage to the engine.
(3) Check fan belt
(Read the instruction manual for the engine furnished separately.)
①
Check the belt for tension and elongation. Also, check it for damage.
Replace if necessary.
②
For adjustment or replacement of the belt, refer to the instruction
manual for the engine.
Press (about 6kg) the position shown by arrow mark (middle of belt) with
your thumb.
The bend should be within the range of 10 mm.
Parts number of fan belt:
Model name
Parts number Parts number of manufacture
DCA-70ESEI Y06020 15256 897362-9260
DCA-125ESEI Y06020 15253 898062-7130
DCA-180ESEI Y06020 15257 113671-5160
(4) Check fuel level
①
Be sure to check the quantity of fuel prior to operation to
prevent lack of fuel during operation.
②
Loosen the drain plug of the fuel tank from time to time,
and remove sediment’s and water at the bottom of the tank.
To Next Page
