8. PRINCIPAL DATA
8-1 Readings on gauges
Marking
Reading Unit
Engine speed 1500 min
-1
Hour meter Adding up H
Engine temperature below 95 °C
Engine oil pressure Between 2 and 5
1)
x100kPa
Battery charging voltage more than 12.5 (70, 125ESEI)
26.0 (180ESEI)
V
Frequency 50 Hz
Load current Below max. rating A
Voltage indicates
Phase-to-phase
volta
g
e
V
1)
If the engine is cold, the pressure may be higher during starting.
8-2 Setting of switches
Switch Function Breaks at Unit
Engine oil pressure Shut-down 0.981 (70/180) ×100kPa
1.0 (125) ×100kPa
Engine coolant temperature Shut-down 105 °C
8-3 Reference conditions
Absolute inlet pressure………………………………………………………................. 100kPa
Relative air humidity…………………………………………………………................. 60%
Air inlet temperature…………………………………………………………................. 27°C
Generator load………………………………………………………………...................continuous
8-4 Limitations
Maximum ambient temperature……………………………………………….............. 40°C
Maximum altitude…………………………………………………………………........... 1000m
Maximum relative air humidity……………………………………………….................85%
